ENGLISH
38
SPECIFICATIONS
SPECIFICATIONS
M2232D
Panel Screen Type 546.1 mm Wide (21.5 inch)
Visible diagonal size : 546.1 mm
Pixel Pitch 0.25 mm (H) x 0.25 mm (V)
Video Signal Max. Resolution 1920 × 1080 @ 60 Hz
Recommended Resolution 1920 × 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 83 kHz
Vertical Frequency 56 Hz to 75 Hz
Synchronization Type Separate Sync, Digital
Input Connector TV, D-Sub Analog, SCART, PC Audio In, Component,
CVBS, HDMI, USB, PCMCIA
Power Rated Voltage 19 V
1.6 A
Power Consumption On Mode : 30 W (typ.)
Off Mode
0.4 W
AC/DC Adapter Manufacturer: Lien Chang, Model LCAP16A-E
Manufacturer: Lien Chang, Model LCAP25A
Tilt Tilt Range -5 to 20°
Dimensions (Width x Depth x Height)
Weight
With Stand
508.6 mm x 180.9 mm x 386.5 mm
3.2 kg
Without Stand
508.6 mm x 62.9 mm x 314.8 mm
2.9 kg
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
Storage Temperature
Storage Humidity
-10 °C to 60 °C
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product
functions.
