Connecting14
Connecting
2
Optional Equipment
Connection
AUX IN Connection
Connect an output of auxiliary device(Camcoder,
TV, Player, etc) to the AUX IN (L/R) connector.
If your device has only one output for audio(mono),
connect it to the left (white) audio jack on the unit.
TV
PORT. IN Connection
Connect an output (earphone or line out) of
portable device (MP3 or PMP etc) to the
PORT. IN connector.
AUDIO OUT connection
You can connect another device.
Connect the left and right AUDIO OUT jacks of the
unit to the audio left and right jacks on another
device using the audio cables.
