3-17
1. WHEN POWER ON, RESET & DATA ETC WAVEFORM
WAVEFORMS OF MAJOR CHECK POINT
SPI DI
SPI DO
TX
LCS3# (FLASH)
1
2
3
4
IC501 pin 72
IC501 pin 46
IC501 pin 47
IC503 pin 1
HRST#
5V
D-
D+
5
6
IC501 pin 91
IC501 pin 90
