1. Multiple piping type MULTI F
10 _ Heat Pump 50Hz/R410A
Part 2 Product data_Outdoor units
Models : A3UW18GFA0 [MU3M19 UE2]
Cooling
5 - - 5 1.5 - - 4,600 1.3 5,000 1.5 6,000 1.8 140 358 578
7 - - 7 2.1 - - 4,600 1.3 7,000 2.1 8,400 2.5 196 502 809
1 Unit 9 - - 9 2.6 - - 5,400 1.6 9,000 2.6 10,800 3.2 252 645 1,040
12 - - 12 3.5 - - 7,200 2.1 12,000 3.5 14,400 4.2 336 860 1,387
18 - - 18 5.3 - - 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
5 5 - 10 1.5 1.5 - 6,000 1.8 10,000 2.9 12,000 3.5 280 717 1,156
5 7 - 12 1.5 2.1 - 7,200 2.1 12,000 3.5 14,400 4.2 336 860 1,387
5 9 - 14 1.5 2.6 - 8,400 2.5 14,000 4.1 16,800 4.9 392 1,003 1,618
5 12 - 17 1.5 3.5 - 10,200 3.0 17,000 5.0 20,400 6.0 476 1,218 1,964
5 18 - 23 1.5 5.3 - 13,800 4.0 23,000 6.7 27,600 8.1 504 1,290 2,080
7 7 - 14 2.1 2.1 - 8,400 2.5 14,000 4.1 16,800 4.9 392 1,003 1,618
2 Unit 7 9 - 16 2.1 2.6 - 9,600 2.8 16,000 4.7 19,200 5.6 448 1,147 1,849
9 9 - 18 2.6 2.6 - 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
7 12 - 19 1.9 3.3 - 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
9 12 - 21 2.3 3.0 - 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
12 12 - 24 2.6 2.6 - 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
7 18 - 25 1.5 3.8 - 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
9 18 - 27 1.8 3.5 - 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
12 18 - 30 2.1 3.2 - 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
5 5 5 15 1.5 1.5 1.5 9,000 2.6 15,000 4.4 18,000 5.3 420 1,075 1,733
5 5 7 17 1.5 1.5 2.1 10,200 3.0 17,000 5.0 20,400 6.0 476 1,218 1,964
5 5 9 19 1.4 1.4 2.5 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
5 5 12 22 1.2 1.2 2.9 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
5 7 7 19 1.4 1.9 1.9 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
5 7 9 21 1.3 1.8 2.3 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
5 7 12 24 1.1 1.5 2.6 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
5 9 9 23 1.1 2.1 2.1 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
3 Unit 5 9 12 26 1.0 1.8 2.4 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
5 12 12 29 0.9 2.2 2.2 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
7 7 7 21 1.8 1.8 1.8 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
7 7 9 23 1.6 1.6 2.1 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
7 9 9 25 1.5 1.9 1.9 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
7 7 12 26 1.4 1.4 2.4 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
9 9 9 27 1.8 1.8 1.8 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
7 9 12 28 1.3 1.7 2.3 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
9 9 12 30 1.6 1.6 2.1 10,800 3.2 18,000 5.3 21,600 6.3 504 1,290 2,080
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Cooling
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Total Unit-A Unit-B Unit-C Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
Note :
1. Cooling Capacity is based on : indoor temp.27°CDB, 19°CWB
; outdoor temp. 35°CDB, 24°CWB
2. Heating Capacity is based on : indoor temp.20°CDB, 15°CWB
; outdoor temp. 7°CDB, 6°CWB
3. Maximum total capacity index of connected indoor units is 30 kBtu/h.
4. At least two indoor units should be connected to outdoor unit.
5. Total capacity of indoor units connected should be minimum 40% of outdoor unit rated capacity.
