Heat pump
50Hz/R410A _ 4
3. Distributor type MULTI F DX (3 phase)
Part 2 Product data_Outdoor units
Note :
1. All data are based on the following conditions:
- Cooling Temperature : Indoor 27°C(80.6°F) DB / 19°C(66.2°F) WB
Outdoor 35°C(95°F) DB / 24°C(75.2°F) WB
- Heating Temperature : Indoor 20°C(68°F) DB / 15°C(59°F) WB
Outdoor 7°C(44.6°F) DB / 6°C(42.8°F) WB
- Piping Length : Interconnected Pipe Length = 5m(Main)+5m(Branch).
- Difference Limit of Elevation (Outdoor ~ Indoor Unit) is Zero.
2. Wiring cable size must comply with the applicable local and national code.
3. Due to our policy of innovation some specifications may be changed without notification.
4. Sound Level Values are measured at Anechoic chamber.
Therefore, these values can be increased owing to ambient conditions during operation.
Outdoor unit
A9UW56LFA0
[FM57AH U32]
Testing Combination MS09AQ NB0 x 7EA
Capacity
Cooling
Min.∼Rated∼Max.
kW 4.0 ~ 15.5 ~ 18.5
Min.∼Rated∼Max.
Btu/h 13,800 ~ 52,900 ~ 63,200
Heating
Min.∼Rated∼Max.
kW 4.5 ~ 17.4 ~ 18.8
Min.∼Rated∼Max.
Btu/h 15,456 ~ 59,400 ~ 64,000
Power Input
Cooling
Min.∼Rated∼Max.
kW 1.00 ~ 3.86 ~ 5.86
Heating
Min.∼Rated∼Max.
kW 1.49 ~ 4.16 ~ 6.19
SEER / SCOP Wh / Wh -
Seasonal Energy Label
Cooling / Heating - -
Annual Energy Consumption
Cooling / Heating kWh -
Power Supply V , Ø , Hz 380-415, 3, 50
Running Current
Cooling
Min.∼Rated∼Max.
A 2.3 ~ 5.4 ~ 8.4
Heating
Min.∼Rated∼Max.
A 2.5 ~ 5.5 ~ 9.0
Starting Current
Cooling Max. A -
Heating Max. A -
Wiring Connections
Power Supply Cable (included Earth)
Outdoor Unit No. x mm
2
(AWG) 5C x 2.5 (12)
Power and transmission cable No. x mm
2
(AWG) 4C x 1.25 (16)
Combination
Sum of Indoor Units Capacity kBtu/h 73
Number of Indoor Units EA 9
Number of BD Units EA 3
Casing Color - Warm Gray
Dimensions
W x H x D mm 950 × 1,380 × 330
W x H x D inch 37-13/32 × 54-11/32 × 13
Net Weight kg (lbs) 96 (211.6)
Compressor
Type - Twin Rotary
Model Model x No. GPT442MAA x 1
Motor type - BLDC
Motor Output W x No. 4,000 (at 60Hz) x 1
Refrigerant
Type - R410A
Precharged Amount g (oz) 4,400 (155.2)
Chargeless-Pipe
Length
Main Pipe m (ft) 5 (16.4)
Branch Pipe m (ft) 45 (147.6)
Additional Charging
Volume
Main Pipe g/m (oz/ft) 20 (0.22)
Branch Pipe g/m (oz/ft) 50 (0.54)
Control - Electronic Expansion Valve
Refrigerant Oil
Type - FVC68D
Charged volume cc x No. 1,300 x 1
Heat Exchanger (Row x Column x Fins per inch) x No. - (2 x 32 x 14) x2
Fan
Type - Propeller
Air Flow Rate - 60 x 2
Fan Motor
Type m
3
/min x No. BLDC
Output W x No. 124.2 x 2
Sound Pressure
Level
Cooling Rated dB(A) 54
Heating Rated dB(A) 56
Sound Power Level Cooling Max. dB(A) 69
Piping Connections
Liquid Outer Dia. mm(inch) x No. Ø 9.52 (3/8)
Gas Outer Dia. mm(inch) x No. Ø 19.05 (3/4)
Piping Length
Total Piping Max. m (ft) 145 (475.7)
Main Piping Max. m (ft) 55 (180.4)
Total Branch Piping Max. m (ft) 90 (295.3)
Each Branch Piping Max. m (ft) 15 (49.2)
Maximum Height
Difference
Outdoor Unit ~ Indoor Unit
Max. m (ft) 30 (98.4)
Indoor Unit ~ Indoor Unit
Max. m (ft) 15 (49.2)
Operation Range
(Outdoor Temperature)
Cooling Min. ~ Max. ℃ DB (℉ DB) -10 (14.0) ~ 48 (118.4)
Heating Min. ~ Max. ℃ WB (℉ WB) -18 (-0.4) ~ 18 (64.4)
