Heat pump
50Hz/R410A _ 6
3. Distributor type MULTI F DX (3 phase)
Part 2 Product data_Outdoor units
[Heating capacity]
Note :
1. Cooling Capacity is based on : indoor temp.27°C DB, 19°C WB
; outdoor temp. 35°C DB, 24°C WB
2. Heating Capacity is based on : indoor temp.20°C DB, 15°C WB
; outdoor temp. 7°C DB, 6°C WB
3. The rated capacities above show the rise in the total indoor unit capacity when operating frequency is constant.
Values for changes in capacity are fixed after accounting for variations in operating frequency and should be used as reference values.
4. Total capacity index of indoor unit should be within 16~54 Btu/h(40%~130%)
5. At least two indoor units should be connected.
16 10,752 3.2 21,633 6.3 25,188 7.4 890 1,066 1,162
18 11,760 3.4 22,407 6.6 25,913 7.6 931 1,116 1,258
19 12,768 3.7 23,182 6.8 26,637 7.8 972 1,166 1,354
20 13,440 3.9 23,956 7.0 27,362 8.0 1,013 1,216 1,450
21 14,112 4.1 24,731 7.2 28,087 8.2 1,055 1,265 1,547
22 14,784 4.3 25,505 7.5 28,811 8.4 1,096 1,315 1,643
23 15,456 4.5 26,279 7.7 29,536 8.7 1,137 1,365 1,739
24 16,023 4.7 27,054 7.9 30,261 8.9 1,178 1,415 1,835
25 16,590 4.9 27,828 8.2 30,985 9.1 1,219 1,465 1,931
26 17,157 5.0 28,602 8.4 31,710 9.3 1,260 1,515 2,027
27 17,724 5.2 29,377 8.6 32,434 9.5 1,301 1,564 2,124
28 18,290 5.4 30,151 8.8 33,159 9.7 1,342 1,614 2,220
29 18,857 5.5 30,926 9.1 33,884 9.9 1,384 1,664 2,316
30 19,424 5.7 31,700 9.3 34,608 10.1 1,425 1,714 2,412
31 19,991 5.9 32,474 9.5 35,333 10.4 1,466 1,764 2,508
32 20,558 6.0 33,249 9.7 36,058 10.6 1,507 1,814 2,604
33 21,125 6.2 34,023 10.0 36,782 10.8 1,548 1,863 2,701
34 21,692 6.4 34,797 10.2 37,507 11.0 1,589 1,913 2,797
35 22,259 6.5 35,572 10.4 38,232 11.2 1,630 1,963 2,893
36 22,825 6.7 36,346 10.7 38,956 11.4 1,672 2,013 2,989
37 23,392 6.9 37,121 10.9 39,681 11.6 1,713 2,063 3,085
38 23,959 7.0 37,895 11.1 40,406 11.8 1,754 2,113 3,181
39 24,526 7.2 38,669 11.3 41,130 12.1 1,795 2,162 3,278
40 25,093 7.4 39,444 11.6 41,855 12.3 1,836 2,212 3,374
41 25,660 7.5 40,218 11.8 42,580 12.5 1,877 2,262 3,470
42 26,227 7.7 40,992 12.0 43,304 12.7 1,918 2,312 3,566
43 26,794 7.9 41,236 12.1 44,029 12.9 1,960 2,345 3,662
44 27,360 8.0 41,480 12.2 44,754 13.1 2,001 2,377 3,758
45 27,927 8.2 41,724 12.2 45,478 13.3 2,042 2,410 3,855
46 28,494 8.4 41,968 12.3 46,203 13.5 2,083 2,442 3,951
47 29,061 8.5 42,212 12.4 46,927 13.8 2,124 2,475 4,047
48 29,628 8.7 42,456 12.4 47,652 14.0 2,165 2,507 4,143
49 30,195 8.8 42,700 12.5 48,377 14.2 2,206 2,540 4,239
50 30,762 9.0 42,870 12.6 49,101 14.4 2,247 2,573 4,335
51 31,329 9.2 43,040 12.6 49,826 14.6 2,289 2,606 4,432
52 31,896 9.3 43,210 12.7 50,551 14.8 2,330 2,639 4,528
53 32,462 9.5 43,380 12.7 51,275 15.0 2,371 2,672 4,624
54 33,029 9.7 43,550 12.8 52,000 15.2 2,412 2,705 4,720
Total indoor unit
capacity
(kBtu/h)
Min
Heating capacity
Rating Max
Btu/h kW Btu/h kW Btu/h kW
Min Rated Max
Input (W)
To Next Page
