Heat pump
50Hz/R410A _ 16
3. Distributor type MULTI F DX (3 phase)
Part 2 Product data_Outdoor units
10 6.17 0.64 6.46 0.65 6.78 0.65 6.95 0.66 7.04 0.66 7.48 0.66 7.81 0.66
12 6.09 0.67 6.38 0.68 6.71 0.68 6.88 0.68 6.97 0.68 7.41 0.69 7.75 0.69
14 6.01 0.70 6.30 0.71 6.63 0.71 6.80 0.71 6.89 0.71 7.34 0.72 7.68 0.73
16 5.92 0.73 6.21 0.74 6.55 0.74 6.72 0.75 6.81 0.75 7.26 0.75 7.60 0.76
18 5.83 0.76 6.12 0.77 6.46 0.78 6.64 0.78 6.73 0.78 7.18 0.79 7.52 0.79
20 5.74 0.80 6.04 0.80 6.37 0.81 6.55 0.81 6.64 0.82 7.09 0.82 7.43 0.83
21 5.70 0.81 5.99 0.82 6.33 0.83 6.51 0.83 6.60 0.83 7.05 0.84 7.39 0.84
23 5.61 0.85 5.91 0.86 6.24 0.86 6.42 0.86 6.51 0.87 6.96 0.87 7.30 0.88
25 5.53 0.88 5.82 0.89 6.15 0.90 6.33 0.90 6.42 0.90 6.87 0.91 7.21 0.91
27 5.44 0.92 5.73 0.92 6.06 0.93 6.24 0.93 6.33 0.93 6.78 0.94 7.12 0.94
29 5.36 0.95 5.65 0.96 5.98 0.96 6.15 0.96 6.24 0.97 6.69 0.97 7.03 0.98
31 5.27 0.98 5.56 0.99 5.89 0.99 6.07 1.00 6.16 1.00 6.60 1.00 6.94 1.01
33 5.19 1.02 5.48 1.02 5.81 1.03 5.98 1.03 6.07 1.03 6.51 1.04 6.85 1.04
35 5.11 1.05 5.40 1.06 5.73 1.06 5.90 1.06 5.99 1.06 6.43 1.07 6.77 1.07
37 5.03 1.09 5.32 1.09 5.64 1.10 5.82 1.10 5.91 1.10 6.35 1.10 6.68 1.11
39 4.95 1.13 5.23 1.13 5.56 1.13 5.74 1.13 5.83 1.14 6.27 1.14 6.60 1.14
41 4.86 1.16 5.15 1.17 5.48 1.17 5.66 1.17 5.75 1.17 6.19 1.18 6.53 1.18
43 4.78 1.21 5.07 1.21 5.40 1.21 5.57 1.21 5.66 1.21 6.11 1.21 6.45 1.22
46 4.63 1.27 4.92 1.27 5.26 1.27 5.44 1.27 5.53 1.27 5.99 1.27 6.33 1.27
10 5.23 0.51 5.47 0.51 5.75 0.52 5.89 0.52 5.97 0.52 6.34 0.53 6.62 0.53
12 5.16 0.53 5.40 0.54 5.68 0.54 5.83 0.54 5.91 0.54 6.28 0.55 6.57 0.55
14 5.09 0.56 5.34 0.56 5.62 0.56 5.77 0.57 5.84 0.57 6.22 0.57 6.51 0.58
16 5.02 0.58 5.26 0.59 5.55 0.59 5.70 0.59 5.77 0.59 6.15 0.60 6.44 0.60
18 4.94 0.61 5.19 0.61 5.47 0.62 5.62 0.62 5.70 0.62 6.08 0.63 6.37 0.63
20 4.87 0.63 5.12 0.64 5.40 0.64 5.55 0.65 5.63 0.65 6.01 0.65 6.30 0.66
21 4.83 0.65 5.08 0.65 5.36 0.66 5.51 0.66 5.59 0.66 5.97 0.67 6.26 0.67
23 4.76 0.67 5.00 0.68 5.29 0.68 5.44 0.69 5.51 0.69 5.90 0.69 6.19 0.70
25 4.68 0.70 4.93 0.71 5.21 0.71 5.36 0.71 5.44 0.71 5.82 0.72 6.11 0.72
27 4.61 0.73 4.86 0.73 5.14 0.74 5.29 0.74 5.36 0.74 5.74 0.75 6.03 0.75
29 4.54 0.75 4.78 0.76 5.07 0.76 5.21 0.77 5.29 0.77 5.67 0.77 5.95 0.78
31 4.47 0.78 4.71 0.78 4.99 0.79 5.14 0.79 5.22 0.79 5.59 0.80 5.88 0.80
33 4.40 0.81 4.64 0.81 4.92 0.82 5.07 0.82 5.15 0.82 5.52 0.82 5.80 0.83
35 4.33 0.83 4.57 0.84 4.85 0.84 5.00 0.84 5.08 0.84 5.45 0.85 5.73 0.85
37 4.26 0.86 4.51 0.87 4.78 0.87 4.93 0.87 5.01 0.87 5.38 0.88 5.66 0.88
39 4.19 0.89 4.44 0.90 4.72 0.90 4.86 0.90 4.94 0.90 5.31 0.90 5.60 0.91
41 4.12 0.92 4.37 0.93 4.65 0.93 4.79 0.93 4.87 0.93 5.25 0.93 5.53 0.94
43 4.05 0.96 4.29 0.96 4.57 0.96 4.72 0.96 4.80 0.96 5.18 0.96 5.47 0.97
46 3.92 1.01 4.17 1.01 4.46 1.01 4.61 1.01 4.69 1.01 5.07 1.01 5.36 1.01
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
Combination
Capacity Index
(kBtu/h(%))
Outdoor Air
Temperature
(°CDB)
14.0 16.0 18.0 19.0 19.5 22.0 24.0
Indoor Air Temperature (°CWB)
Notes:
1. Capacities are based on the following conditions.
Main Piping Length 5m, Branch Piping Length 5m
Level difference : 0m
2. TC : Total Capacity (kW)
PI : Power Input (kW)
21
(50%)
16
(40%)
To Next Page
