Heat pump 50Hz/R410A _ 28
3. Distributor type MULTI F DX (3 phase)
Part 2 Product data_Outdoor units
Notes:
1. Capacities are based on the following conditions.
Main Piping Length 5m, Branch Piping Length 5m
Level difference : 0m
2. TC : Total Capacity (kW)
PI : Power Input (kW)
10 8.37 1.06 8.75 1.07 9.20 1.08 9.43 1.08 9.55 1.09 10.14 1.09 10.59 1.10
12 8.26 1.11 8.65 1.12 9.10 1.13 9.33 1.13 9.45 1.13 10.05 1.14 10.51 1.15
14 8.14 1.16 8.54 1.17 8.99 1.18 9.23 1.18 9.35 1.18 9.95 1.19 10.41 1.20
16 8.03 1.21 8.42 1.22 8.88 1.23 9.12 1.23 9.24 1.24 9.85 1.25 10.31 1.25
18 7.91 1.26 8.30 1.27 8.76 1.28 9.00 1.29 9.12 1.29 9.73 1.30 10.20 1.31
20 7.79 1.32 8.19 1.33 8.64 1.34 8.88 1.35 9.00 1.35 9.62 1.36 10.08 1.37
21 7.73 1.35 8.13 1.36 8.58 1.37 8.82 1.37 8.94 1.38 9.56 1.39 10.02 1.40
23 7.61 1.40 8.01 1.42 8.46 1.43 8.70 1.43 8.82 1.43 9.43 1.44 9.90 1.45
25 7.49 1.46 7.89 1.47 8.34 1.48 8.58 1.49 8.70 1.49 9.31 1.50 9.77 1.51
27 7.38 1.52 7.77 1.53 8.22 1.54 8.46 1.54 8.58 1.54 9.19 1.55 9.65 1.56
29 7.26 1.57 7.66 1.58 8.11 1.59 8.34 1.59 8.46 1.60 9.07 1.61 9.53 1.62
31 7.15 1.63 7.54 1.63 7.99 1.64 8.23 1.65 8.35 1.65 8.95 1.66 9.41 1.67
33 7.04 1.68 7.43 1.69 7.88 1.70 8.11 1.70 8.23 1.70 8.83 1.71 9.29 1.72
35 6.93 1.74 7.32 1.75 7.76 1.75 8.00 1.76 8.12 1.76 8.72 1.77 9.17 1.78
37 6.82 1.80 7.21 1.81 7.65 1.81 7.89 1.82 8.01 1.82 8.61 1.83 9.06 1.83
39 6.71 1.86 7.10 1.87 7.54 1.87 7.78 1.88 7.90 1.88 8.50 1.88 8.95 1.89
41 6.60 1.93 6.99 1.93 7.43 1.94 7.67 1.94 7.79 1.94 8.39 1.95 8.85 1.95
43 6.48 1.99 6.87 2.00 7.32 2.00 7.56 2.00 7.68 2.01 8.29 2.01 8.74 2.01
46 6.28 2.10 6.68 2.10 7.13 2.10 7.38 2.10 7.50 2.10 8.12 2.10 8.58 2.10
10 6.90 0.88 7.22 0.89 7.59 0.90 7.78 0.90 7.88 0.90 8.37 0.91 8.74 0.91
12 6.81 0.92 7.13 0.93 7.50 0.94 7.70 0.94 7.80 0.94 8.29 0.95 8.67 0.95
14 6.72 0.96 7.04 0.97 7.42 0.98 7.61 0.98 7.71 0.98 8.21 0.99 8.59 1.00
16 6.62 1.00 6.95 1.01 7.32 1.02 7.52 1.02 7.62 1.03 8.12 1.04 8.51 1.04
18 6.52 1.05 6.85 1.06 7.23 1.07 7.42 1.07 7.53 1.07 8.03 1.08 8.41 1.09
20 6.43 1.10 6.75 1.10 7.13 1.11 7.33 1.12 7.43 1.12 7.93 1.13 8.32 1.14
21 6.38 1.12 6.70 1.13 7.08 1.14 7.28 1.14 7.38 1.14 7.88 1.15 8.27 1.16
23 6.28 1.17 6.61 1.18 6.98 1.18 7.18 1.19 7.28 1.19 7.78 1.20 8.17 1.21
25 6.18 1.21 6.51 1.22 6.88 1.23 7.08 1.23 7.18 1.24 7.68 1.25 8.06 1.25
27 6.09 1.26 6.41 1.27 6.78 1.28 6.98 1.28 7.08 1.28 7.58 1.29 7.96 1.30
29 5.99 1.30 6.32 1.31 6.69 1.32 6.88 1.32 6.98 1.33 7.48 1.33 7.86 1.34
31 5.90 1.35 6.22 1.36 6.59 1.37 6.79 1.37 6.89 1.37 7.38 1.38 7.76 1.39
33 5.81 1.40 6.13 1.40 6.50 1.41 6.69 1.41 6.79 1.42 7.29 1.42 7.66 1.43
35 5.72 1.44 6.04 1.45 6.41 1.46 6.60 1.46 6.70 1.46 7.19 1.47 7.57 1.47
37 5.63 1.49 5.95 1.50 6.31 1.51 6.51 1.51 6.61 1.51 7.10 1.52 7.48 1.52
39 5.54 1.55 5.86 1.55 6.22 1.56 6.42 1.56 6.52 1.56 7.01 1.56 7.39 1.57
41 5.44 1.60 5.76 1.60 6.13 1.61 6.33 1.61 6.43 1.61 6.92 1.62 7.30 1.62
43 5.34 1.66 5.67 1.66 6.04 1.66 6.24 1.66 6.34 1.67 6.84 1.67 7.21 1.67
46 5.18 1.74 5.51 1.74 5.89 1.74 6.09 1.74 6.19 1.75 6.70 1.75 7.08 1.75
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
Combination
Capacity Index
(kBtu/h(%))
Outdoor Air
Temperature
(°CDB)
14.0 16.0 18.0 19.0 19.5 22.0 24.0
Indoor Air Temperature (°CWB)
28
(50%)
23
(40%)
To Next Page
