3. Distributor type MULTI F DX (3 phase)
31 _ Heat pump 50Hz/R410A
Part 2 Product data_Outdoor units
Notes:
1. Capacities are based on the following conditions.
Main Piping Length 5m, Branch Piping Length 5m
Level difference : 0m
2. TC : Total Capacity (kW)
PI : Power Input (kW)
-15.0 7.41 2.35 7.40 2.40 7.40 2.46 7.40 2.49 7.40 2.52 7.40 2.58
-13.0 7.63 2.38 7.62 2.43 7.62 2.48 7.73 2.52 7.73 2.54 7.74 2.60
-11.0 7.84 2.42 7.84 2.46 7.84 2.50 7.93 2.53 7.93 2.56 7.94 2.61
-10.0 7.95 2.43 7.95 2.47 7.95 2.51 8.04 2.54 8.04 2.56 8.04 2.61
-9.1 8.05 2.45 8.05 2.48 8.04 2.52 8.13 2.55 8.13 2.57 8.13 2.62
-7.6 8.22 2.47 8.21 2.50 8.21 2.54 8.28 2.56 8.28 2.58 8.28 2.62
-5.6 8.43 2.50 8.43 2.53 8.43 2.56 8.48 2.58 8.48 2.60 8.48 2.63
-3.7 8.64 2.53 8.64 2.56 8.64 2.58 8.67 2.60 8.67 2.61 8.67 2.64
-0.7 8.97 2.58 8.97 2.60 8.97 2.61 8.97 2.62 8.97 2.63 8.97 2.65
0.0 9.05 2.59 9.04 2.61 9.04 2.62 9.04 2.63 9.04 2.64 9.04 2.66
1.0 9.15 2.61 9.15 2.62 9.15 2.63 9.14 2.64 9.14 2.65 9.14 2.66
2.2 9.29 2.63 9.28 2.64 9.28 2.65 9.26 2.65 9.26 2.65 9.26 2.67
4.1 9.49 2.66 9.49 2.66 9.49 2.67 9.45 2.67 9.45 2.67 9.45 2.68
6.0 9.79 2.55 9.74 2.62 9.70 2.69 9.65 2.68 9.65 2.68 9.65 2.68
7.9 10.17 2.60 10.13 2.67 10.10 2.75 10.09 2.78 10.08 2.83 10.07 2.91
9.8 10.59 2.65 10.55 2.73 10.53 2.81 10.52 2.85 10.52 2.90 10.51 2.99
11.8 11.06 2.72 11.03 2.81 11.02 2.89 11.01 2.93 11.01 2.98 11.00 3.07
13.7 11.54 2.79 11.52 2.88 11.50 2.97 11.49 3.01 11.48 3.06 11.45 3.15
15.0 11.88 2.84 11.86 2.93 11.83 3.01 11.81 3.06 11.79 3.10 11.73 3.20
18.0 12.65 2.91 12.58 3.00 12.49 3.08 12.43 3.12 12.36 3.15 12.16 3.23
-15.0 6.27 1.99 6.27 2.03 6.27 2.08 6.27 2.10 6.27 2.13 6.28 2.19
-13.0 6.45 2.01 6.45 2.06 6.45 2.10 6.55 2.13 6.55 2.15 6.56 2.20
-11.0 6.63 2.04 6.64 2.08 6.64 2.12 6.72 2.14 6.72 2.16 6.73 2.21
-10.0 6.73 2.05 6.73 2.09 6.73 2.12 6.81 2.15 6.81 2.17 6.81 2.21
-9.1 6.81 2.07 6.81 2.10 6.81 2.13 6.88 2.16 6.88 2.17 6.89 2.21
-7.6 6.95 2.09 6.95 2.12 6.95 2.15 7.01 2.17 7.01 2.18 7.01 2.22
-5.6 7.13 2.11 7.13 2.14 7.13 2.16 7.18 2.18 7.18 2.20 7.18 2.23
-3.7 7.31 2.14 7.31 2.16 7.31 2.18 7.34 2.19 7.34 2.21 7.34 2.23
-0.7 7.58 2.18 7.58 2.19 7.58 2.21 7.59 2.22 7.59 2.22 7.59 2.24
0.0 7.65 2.19 7.65 2.20 7.65 2.21 7.65 2.22 7.65 2.23 7.65 2.24
1.0 7.74 2.20 7.74 2.21 7.74 2.22 7.73 2.23 7.73 2.23 7.73 2.25
2.2 7.85 2.22 7.85 2.22 7.85 2.23 7.83 2.24 7.83 2.24 7.84 2.25
4.1 8.02 2.24 8.03 2.25 8.03 2.25 7.99 2.25 7.99 2.25 7.99 2.26
6.0 8.30 2.16 8.25 2.21 8.20 2.27 8.15 2.26 8.15 2.26 8.15 2.27
7.9 8.62 2.20 8.57 2.25 8.52 2.31 8.51 2.34 8.49 2.37 8.47 2.44
9.8 8.95 2.24 8.91 2.30 8.87 2.36 8.85 2.39 8.84 2.43 8.82 2.50
11.8 9.33 2.29 9.29 2.36 9.26 2.42 9.24 2.45 9.23 2.49 9.20 2.56
13.7 9.71 2.34 9.68 2.41 9.64 2.48 9.62 2.51 9.60 2.55 9.56 2.62
15.0 9.98 2.38 9.94 2.44 9.90 2.51 9.87 2.54 9.85 2.58 9.78 2.65
18.0 10.58 2.43 10.51 2.49 10.41 2.55 10.35 2.58 10.28 2.61 10.10 2.67
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
Combination
Capacity Index
(kBtu/h(%))
Outdoor Air
Temperature
(°CWB)
16.0 18.0 20.0 21.0 22.0 24.0
Indoor Air Temperature (°CDB)
28
(50%)
23
(40%)
