1. Multiple piping type MULTI F
16 _
Heat Pump
50Hz/R410A
Part 2 Product data_Outdoor units
Heating
5 - - - 5 1.6 - - - 4,950 1.5 5,500 1.6 6,050 1.8 498 830 1,294
7 - - - 7 2.3 - - - 7,560 2.2 8,000 2.3 8,800 2.6 510 850 1,294
1 UNIT
9 - - - 9 2.9 - - - 7,560 2.2 10,000 2.9 10,900 3.2 534 890 1,471
12 - - - 12 3.9 - - - 7,920 2.3 13,200 3.9 14,500 4.2 582 970 1,676
18 - - - 18 5.8 - - - 11,880 3.5 19,800 5.8 21,800 6.4 1,152 1,920 2,157
24 - - - 24 7.4 - - - 15,240 4.5 25,400 7.4 26,600 7.8 1,416 2,360 3,431
5 5 - - 10 1.6 1.6 - - 6,600 1.9 11,000 3.2 12,100 3.5 720 1,200 1,265
5 7 - - 12 1.6 2.5 - - 8,340 2.4 13,900 4.1 15,290 4.5 732 1,220 2,301
5 9 - - 14 1.6 2.9 - - 9,300 2.7 15,500 4.5 18,500 5.4 762 1,270 2,167
7 7 - - 14 2.5 2.5 - - 10,080 3.0 16,800 4.9 18,500 5.4 762 1,270 2,507
7 9 - - 16 2.5 3.2 - - 11,520 3.4 19,200 5.6 21,100 6.2 834 1,390 2,167
5 12 - - 17 1.6 3.9 - - 11,220 3.3 18,700 5.5 23,700 6.9 858 1,430 2,735
9 9 - - 18 3.2 3.2 - - 12,960 3.8 21,600 6.3 23,700 6.9 1,104 1,840 2,931
7 12 - - 19 2.5 4.2 - - 13,680 4.0 22,800 6.7 25,000 7.3 1,206 2,010 3,039
2 UNIT
9 12 - - 21 3.2 4.2 - - 15,120 4.4 25,200 7.4 27,700 8.1 1,356 2,260 3,225
5 18 - - 23 1.6 5.8 - - 15,180 4.4 25,300 7.4 27,830 8.2 1,524 2,540 3,255
12 12 - - 24 3.9 3.9 - - 15,840 4.6 26,400 7.7 29,040 8.5 1,608 2,680 3,412
7 18 - - 25 2.3 5.9 - - 16,680 4.9 27,800 8.1 30,000 8.8 1,608 2,680 3,412
9 18 - - 27 2.8 5.6 - - 17,280 5.1 28,800 8.4 31,500 9.2 1,608 2,680 3,412
5 24 - - 29 1.5 7.0 - - 17,280 5.1 28,800 8.4 32,000 9.4 1,608 2,680 3,412
12 18 - - 30 3.4 5.1 - - 17,280 5.1 28,800 8.4 32,000 9.4 1,608 2,680 3,412
7 24 - - 31 1.9 6.5 - - 17,280 5.1 28,800 8.4 32,000 9.4 1,608 2,680 3,412
9 24 - - 33 2.3 6.1 - - 17,280 5.1 28,800 8.4 32,000 9.4 1,608 2,680 3,412
18 18 - - 36 4.2 4.2 - - 17,280 5.1 28,800 8.4 32,000 9.4 1,608 2,680 3,412
12 24 - - 36 2.8 5.6 - - 17,280 5.1 28,800 8.4 32,000 9.4 1,608 2,680 3,412
5 5 5 - 15 1.6 1.6 1.6 - 9,900 2.9 16,500 4.8 18,150 5.3 870 1,450 1,598
5 5 7 - 17 1.6 1.6 2.5 - 11,640 3.4 19,400 5.7 21,340 6.3 936 1,560 1,951
5 5 9 - 19 1.6 1.6 2.9 - 12,600 3.7 21,000 6.2 23,100 6.8 966 1,610 2,373
5 7 7 - 19 1.6 2.5 2.3 - 13,140 3.9 21,900 6.4 24,090 7.1 966 1,610 2,373
5 7 9 - 21 1.6 2.5 2.9 - 14,340 4.2 23,900 7.0 26,290 7.7 1,026 1,710 2,873
7 7 7 - 21 2.5 2.5 2.5 - 15,120 4.4 25,200 7.4 27,700 8.1 1,026 1,710 2,873
5 5 12 - 22 1.6 1.6 3.9 - 14,520 4.3 24,200 7.1 26,620 7.8 1,050 1,750 3,049
7 7 9 - 23 2.5 2.5 3.2 - 16,560 4.9 27,600 8.1 30,000 8.8 1,122 1,870 3,275
5 9 9 - 23 1.6 2.9 2.9 - 15,300 4.5 25,500 7.5 28,050 8.2 1,122 1,870 3,275
5 7 12 - 24 1.8 2.5 4.2 - 17,280 5.1 28,800 8.4 31,500 9.2 1,188 1,980 3,647
7 9 9 - 25 2.4 3.0 3.0 - 17,280 5.1 28,800 8.4 30,000 8.8 1,188 1,980 3,647
5 9 12 - 26 1.6 2.9 3.9 - 17,280 5.1 28,800 8.4 31,500 9.2 1,188 1,980 3,647
7 7 12 - 26 2.3 2.3 3.9 - 17,280 5.1 28,800 8.4 31,500 9.2 1,188 1,980 3,647
9 9 9 - 27 2.8 2.8 2.8 - 17,280 5.1 28,800 8.4 31,500 9.2 1,188 1,980 3,647
7 9 12 - 28 2.1 2.7 3.6 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
5 5 18 - 28 1.5 1.5 5.4 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
3 UNIT 5 12 12 - 29 1.5 3.5 3.5 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
5 7 18 - 30 1.4 2.0 5.1 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
9 9 12 - 30 2.5 2.5 3.4 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
7 12 12 - 31 1.9 3.3 3.3 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
5 9 18 - 32 1.3 2.4 4.7 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
7 7 18 - 32 1.8 1.8 4.7 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
9 12 12 - 33 2.3 3.1 3.1 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
7 9 18 - 34 1.7 2.2 4.5 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
5 5 24 - 34 1.2 1.2 6.0 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
5 12 18 - 35 1.2 2.9 4.3 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
5 7 24 - 36 1.2 1.6 5.6 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
12 12 12 - 36 2.8 2.8 2.8 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
9 9 18 - 36 2.1 2.1 4.2 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
7 12 18 - 37 1.6 2.7 4.1 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
5 9 24 - 38 1.1 2.0 5.3 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
7 7 24 - 38 1.6 1.6 5.3 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
9 12 18 - 39 1.9 2.6 3.9 - 17,280 5.1 28,800 8.4 32,000 9.4 1,188 1,980 3,647
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Heating
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Unit-D Total Unit-A Unit-B Unit-C Unit-D Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
