1. Multiple piping type MULTI F
20 _
Heat Pump
50Hz/R410A
Part 2 Product data_Outdoor units
Heating
5 - - - 5 1.6 - - - 5,000 1.5 5,500 1.6 6,050 1.8 498 830 1,256
7 - - - 7 2.3 - - - 7,560 2.2 8,000 2.3 8,800 2.6 510 850 1,256
9 - - - 9 2.9 - - - 7,560 2.2 10,000 2.9 11,000 3.2 534 890 1,428
12 - - - 12 3.9 - - - 7,920 2.3 13,200 3.9 14,520 4.3 582 970 1,628
18 - - - 18 5.8 - - - 11,880 3.5 19,800 5.8 21,780 6.4 1,152 1,920 2,094
24 - - - 24 7.4 - - - 15,240 4.5 25,400 7.4 26,600 7.8 1,416 2,360 3,331
5 5 - - 10 1.8 1.8 - - 7,200 2.1 12,000 3.5 13,800 4.0 720 1,200 1,228
5 7 - - 12 1.8 2.5 - - 8,640 2.5 14,400 4.2 16,560 4.9 732 1,220 2,234
5 9 - - 14 1.8 3.2 - - 10,080 3.0 16,800 4.9 19,320 5.7 762 1,270 2,104
7 7 - - 14 2.5 2.5 - - 10,080 3.0 16,800 4.9 19,320 5.7 762 1,270 2,434
7 9 - - 16 2.5 3.2 - - 11,520 3.4 19,200 5.6 22,080 6.5 834 1,390 2,104
5 12 - - 17 1.8 4.2 - - 12,240 3.6 20,400 6.0 22,440 6.6 858 1,430 2,656
9 9 - - 18 3.2 3.2 - - 12,960 3.8 21,600 6.3 24,840 7.3 1,104 1,840 2,846
7 12 - - 19 2.5 4.2 - - 13,680 4.0 22,800 6.7 25,080 7.4 1,206 2,010 2,951
9 12 - - 21 3.2 4.2 - - 15,120 4.4 25,200 7.4 27,720 8.1 1,356 2,260 3,132
5 18 - - 23 1.8 6.3 - - 16,560 4.9 27,600 8.1 31,740 9.3 1,524 2,540 3,160
12 12 - - 24 4.2 4.2 - - 17,280 5.1 28,800 8.4 31,680 9.3 1,608 2,680 3,312
7 18 - - 25 2.5 6.3 - - 18,000 5.3 30,000 8.8 33,000 9.7 1,656 2,760 3,474
9 18 - - 27 3.2 6.3 - - 19,440 5.7 31,000 9.1 34,100 10.0 1,728 2,880 3,522
5 24 - - 29 1.7 8.1 - - 20,010 5.9 31,000 9.1 34,100 10.0 1,728 2,880 3,522
12 18 - - 30 4.0 6.1 - - 20,700 6.1 31,000 9.1 34,100 10.0 1,728 2,880 3,522
7 24 - - 31 2.3 7.8 - - 20,700 6.1 31,000 9.1 34,100 10.0 1,728 2,880 3,522
9 24 - - 33 2.8 7.4 - - 20,700 6.1 31,000 9.1 34,100 10.0 1,728 2,880 3,522
18 18 - - 36 5.1 5.1 - - 20,700 6.1 31,000 9.1 34,100 10.0 1,728 2,880 3,522
12 24 - - 36 3.4 6.7 - - 20,700 6.1 31,000 9.1 34,100 10.0 1,728 2,880 3,522
5 5 5 - 15 1.8 1.8 1.8 - 10,800 3.2 18,000 5.3 20,160 5.9 870 1,450 1,551
5 5 7 - 17 1.8 1.8 2.5 - 12,240 3.6 20,400 6.0 22,848 6.7 936 1,560 1,894
5 5 9 - 19 1.8 1.8 3.2 - 13,680 4.0 22,800 6.7 25,536 7.5 966 1,610 2,303
5 7 7 - 19 1.8 2.5 2.5 - 13,680 4.0 22,800 6.7 25,536 7.5 966 1,610 2,303
5 7 9 - 21 1.8 2.5 3.2 - 15,120 4.4 25,200 7.4 28,224 8.3 1,026 1,710 2,789
7 7 7 - 21 2.5 2.5 2.5 - 15,120 4.4 25,200 7.4 28,224 8.3 1,026 1,710 2,789
5 5 12 - 22 1.8 1.8 4.2 - 15,840 4.6 26,400 7.7 29,568 8.7 1,050 1,750 2,960
7 7 9 - 23 2.5 2.5 3.2 - 16,560 4.9 27,600 8.1 30,912 9.1 1,122 1,870 3,179
5 9 9 - 23 1.8 3.2 3.2 - 16,560 4.9 27,600 8.1 30,912 9.1 1,122 1,870 3,179
5 7 12 - 24 1.8 2.5 4.2 - 17,280 5.1 28,800 8.4 32,256 9.5 1,188 1,980 3,541
7 9 9 - 25 2.5 3.2 3.2 - 18,000 5.3 30,000 8.8 33,600 9.8 1,260 2,100 3,626
5 9 12 - 26 1.8 3.2 4.2 - 18,720 5.5 30,000 8.8 33,600 9.8 1,326 2,210 3,626
7 7 12 - 26 2.5 2.5 4.2 - 18,720 5.5 30,000 8.8 33,600 9.8 1,326 2,210 3,626
9 9 9 - 27 3.2 3.2 3.2 - 19,440 5.7 31,000 9.1 34,720 10.2 1,428 2,380 3,730
7 9 12 - 28 2.5 3.2 4.2 - 20,160 5.9 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 5 18 - 28 1.8 1.8 6.3 - 20,160 5.9 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 12 12 - 29 1.8 4.2 4.2 - 20,880 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 7 18 - 30 1.7 2.4 6.1 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
9 9 12 - 30 3.0 3.0 4.0 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
7 12 12 - 31 2.3 3.9 3.9 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 9 18 - 32 1.6 2.8 5.7 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
7 7 18 - 32 2.2 2.2 5.7 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
9 12 12 - 33 2.8 3.7 3.7 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
7 9 18 - 34 2.1 2.7 5.4 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 5 24 - 34 1.5 1.5 7.1 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 12 18 - 35 1.4 3.5 5.2 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 7 24 - 36 1.4 2.0 6.7 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
12 12 12 - 36 3.4 3.4 3.4 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
9 9 18 - 36 2.5 2.5 5.1 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
7 12 18 - 37 1.9 3.3 4.9 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 9 24 - 38 1.3 2.4 6.4 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
7 7 24 - 38 1.9 1.9 6.4 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
9 12 18 - 39 2.3 3.1 4.7 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
7 9 24 - 40 1.8 2.3 6.1 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 12 24 - 41 1.2 3.0 5.9 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
5 18 18 - 41 1.2 4.4 4.4 - 20,700 6.1 31,000 9.1 34,720 10.2 1,428 2,380 3,730
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Cooling
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Unit-D Total Unit-A Unit-B Unit-C Unit-D Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
1 UNIT
2 UNIT
3 UNIT
