1. Multiple piping type MULTI F
28 _
Heat Pump
50Hz/R410A
Part 2 Product data_Outdoor units
Models : A5UW40GFA0 [MU5M40 UO2]
Cooling
5 - - - - 5 1.5 - - - - 3,000 0.9 5,000 1.5 6,000 1.8 780 1,120 1,703
7 - - - - 7 2.1 - - - - 4,200 1.2 7,000 2.1 8,400 2.5 780 1,120 1,703
9 - - - - 9 2.6 - - - - 5,400 1.6 9,000 2.6 10,800 3.2 780 1,120 1,703
12 - - - - 12 3.5 - - - - 7,200 2.1 12,000 3.5 14,400 4.2 780 1,120 1,703
18 - - - - 18 5.3 - - - - 10,800 3.2 18,000 5.3 21,600 6.3 800 1,260 1,915
24 - - - - 24 7.0 - - - - 14,400 4.2 24,000 7.0 28,800 8.4 1,042 1,680 2,554
5 5 - - - 10 1.5 1.5 - - - 6,000 1.8 10,000 2.9 12,000 3.5 780 1,120 1,703
5 7 - - - 12 1.5 2.1 - - - 7,200 2.1 12,000 3.5 14,400 4.2 780 1,120 1,703
5 9 - - - 14 1.5 2.6 - - - 8,400 2.5 14,000 4.1 16,800 4.9 780 1,120 1,703
7 7 - - - 14 2.1 2.1 - - - 8,400 2.5 14,000 4.1 16,800 4.9 780 1,120 1,703
7 9 - - - 16 2.1 2.6 - - - 9,600 2.8 16,000 4.7 19,200 5.6 780 1,120 1,703
5 12 - - - 17 1.5 3.5 - - - 10,200 3.0 17,000 5.0 20,400 6.0 780 1,190 1,809
9 9 - - - 18 2.6 2.6 - - - 10,800 3.2 18,000 5.3 21,600 6.3 800 1,260 1,915
7 12 - - - 19 2.1 3.5 - - - 11,400 3.3 19,000 5.6 22,800 6.7 825 1,330 2,022
9 12 - - - 21 2.6 3.5 - - - 12,600 3.7 21,000 6.2 25,200 7.4 911 1,470 2,235
5 18 - - - 23 1.5 5.3 - - - 13,800 4.0 23,000 6.7 27,600 8.1 998 1,610 2,447
12 12 - - - 24 3.5 3.5 - - - 14,400 4.2 24,000 7.0 28,800 8.4 1,042 1,680 2,554
7 18 - - - 25 2.1 5.3 - - - 15,000 4.4 25,000 7.3 30,000 8.8 1,085 1,750 2,660
9 18 - - - 27 2.6 5.3 - - - 16,200 4.7 27,000 7.9 32,400 9.5 1,172 1,890 2,873
5 24 - - - 29 1.5 7.0 - - - 17,400 5.1 29,000 8.5 34,800 10.2 1,259 2,030 3,086
12 18 - - - 30 3.5 5.3 - - - 18,000 5.3 30,000 8.8 36,000 10.6 1,302 2,100 3,192
7 24 - - - 31 2.1 7.0 - - - 18,600 5.5 31,000 9.1 37,200 10.9 1,345 2,170 3,299
9 24 - - - 33 2.6 7.0 - - - 19,800 5.8 33,000 9.7 39,600 11.6 1,432 2,310 3,512
18 18 - - - 36 5.3 5.3 - - - 21,600 6.3 36,000 10.6 43,200 12.7 1,562 2,520 3,831
12 24 - - - 36 3.5 7.0 - - - 21,600 6.3 36,000 10.6 43,200 12.7 1,562 2,520 3,831
18 24 - - - 42 5.0 6.7 - - - 24,000 7.0 40,000 11.7 46,000 13.5 1,693 2,730 4,150
24 24 - - - 48 5.9 5.9 - - - 24,000 7.0 40,000 11.7 46,000 13.5 1,693 2,730 4,150
5 5 5 - - 15 1.5 1.5 1.5 - - 9,000 2.6 15,000 4.4 18,000 5.3 780 1,120 1,703
5 5 7 - - 17 1.5 1.5 2.1 - - 10,200 3.0 17,000 5.0 20,400 6.0 780 1,190 1,809
5 5 9 - - 19 1.5 1.5 2.6 - - 11,400 3.3 19,000 5.6 22,800 6.7 825 1,330 2,022
5 7 7 - - 19 1.5 2.1 2.1 - - 11,400 3.3 19,000 5.6 22,800 6.7 825 1,330 2,022
5 7 9 - - 21 1.5 2.1 2.6 - - 12,600 3.7 21,000 6.2 25,200 7.4 911 1,470 2,235
7 7 7 - - 21 2.1 2.1 2.1 - - 12,600 3.7 21,000 6.2 25,200 7.4 911 1,470 2,235
5 5 12 - - 22 1.5 1.5 3.7 - - 13,800 4.0 23,000 6.7 27,600 8.1 952 1,540 2,341
7 7 9 - - 23 2.1 2.1 2.6 - - 13,800 4.0 23,000 6.7 27,600 8.1 998 1,610 2,447
5 9 9 - - 23 1.5 2.6 2.6 - - 13,800 4.0 23,000 6.7 27,600 8.1 998 1,610 2,447
5 7 12 - - 24 1.5 2.1 3.5 - - 14,400 4.2 24,000 7.0 28,800 8.4 1,042 1,680 2,554
7 9 9 - - 25 2.1 2.6 2.6 - - 15,000 4.4 25,000 7.3 30,000 8.8 1,085 1,750 2,660
5 9 12 - - 26 1.5 2.6 3.5 - - 15,600 4.6 26,000 7.6 31,200 9.1 1,128 1,820 2,767
7 7 12 - - 26 2.1 2.1 3.5 - - 15,600 4.6 26,000 7.6 31,200 9.1 1,128 1,820 2,767
9 9 9 - - 27 2.6 2.6 2.6 - - 16,200 4.7 27,000 7.9 32,400 9.5 1,172 1,890 2,873
7 9 12 - - 28 2.1 2.6 3.5 - - 16,800 4.9 28,000 8.2 33,600 9.8 1,215 1,960 2,979
5 5 18 - - 28 1.5 1.5 5.3 - - 16,800 4.9 28,000 8.2 33,600 9.8 1,215 1,960 2,979
5 12 12 - - 29 1.5 3.5 3.5 - - 17,400 5.1 29,000 8.5 34,800 10.2 1,259 2,030 3,086
5 7 18 - - 30 1.5 2.1 5.3 - - 18,000 5.3 30,000 8.8 36,000 10.6 1,302 2,100 3,192
9 9 12 - - 30 2.6 2.6 3.5 - - 18,000 5.3 30,000 8.8 36,000 10.6 1,302 2,100 3,192
7 12 12 - - 31 2.1 3.5 3.5 - - 18,600 5.5 31,000 9.1 37,200 10.9 1,345 2,170 3,299
5 9 18 - - 32 1.5 2.6 5.3 - - 19,200 5.6 32,000 9.4 38,400 11.3 1,389 2,240 3,405
7 7 18 - - 32 2.1 2.1 5.3 - - 19,200 5.6 32,000 9.4 38,400 11.3 1,389 2,240 3,405
9 12 12 - - 33 2.6 3.5 3.5 - - 19,800 5.8 33,000 9.7 39,600 11.6 1,432 2,310 3,512
7 9 18 - - 34 2.1 2.6 5.3 - - 20,400 6.0 34,000 10.0 40,800 12.0 1,476 2,380 3,618
5 5 24 - - 34 1.5 1.5 7.0 - - 20,400 6.0 34,000 10.0 40,800 12.0 1,476 2,380 3,618
5 12 18 - - 35 1.5 3.5 5.3 - - 21,000 6.2 35,000 10.3 42,000 12.3 1,519 2,450 3,724
5 7 24 - - 36 1.5 2.1 7.0 - - 21,600 6.3 36,000 10.6 43,200 12.7 1,562 2,520 3,831
12 12 12 - - 36 3.5 3.5 3.5 - - 21,600 6.3 36,000 10.6 43,200 12.7 1,562 2,520 3,831
9 9 18 - - 36 2.6 2.6 5.3 - - 21,600 6.3 36,000 10.6 43,200 12.7 1,562 2,520 3,831
7 12 18 - - 37 2.1 3.5 5.3 - - 22,200 6.5 37,000 10.8 44,400 13.0 1,606 2,590 3,937
5 9 24 - - 38 1.5 2.6 7.0 - - 22,800 6.7 38,000 11.1 45,600 13.4 1,649 2,660 4,044
7 7 24 - - 38 2.1 2.1 7.0 - - 22,800 6.7 38,000 11.1 45,600 13.4 1,649 2,660 4,044
9 12 18 - - 39 2.6 3.4 5.2 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
7 9 24 - - 40 2.0 2.5 6.7 - - 22,920 6.7 38,200 11.2 46,000 13.5 1,693 2,730 4,150
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Cooling
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Unit-D Unit-E Total Unit-A Unit-B Unit-C Unit-D Unit-E Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
1 UNIT
2 UNIT
3 UNIT
To Next Page
