GENERAL DATA
0XOWL)2XWGRRU8QLW'LPHQVLRQV
Figure 1: LMU18CHV Multi F Outdoor Unit External Dimensions.
1. Unit should be installed in compliance with the installation manual in
the product box.
2. Unit should be grounded in accordance with the local regulations or
applicable national codes.
3. All electrical components and materials to be supplied on the site
must comply with the local regulations or international codes.
4. Electrical characteristics chapter should be considered for electrical
work and design. Especially the capacity of power cable and circuit
breaker for outdoor unit should be more than that of electrical
characteristics chapter.
Note
Gas pipe connection
Part Name
Air discharge grille
Liquid pipe connection
Power & transmission connection
No.
2
4
Main service valve(Gas)
Main service valve(Liquid)
5
6
3
1
[Unit : mm(inch)]
Gravity point
