LG MULTI F MAX User Manual

MULTI
F
MAX
MULTI
F
15
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Nominal
Tons
Unit Model
No.
Hertz Voltage Phase
Voltage
Range
(Min. to Max.)
MCA MOP
Compressor
Quantity
Compressor
Motor RLA
Condenser Fan Motor(s)
Indoor
Fan
Motor
Condenser
Fan Quantity
x kW
Condenser
Fan Motor
FLA
4.0 LMU480HV 60 208 - 230
1
187 - 253 27.3 40 1 17.5 2 x 0.12 0.73 x 2 4.0
4.5 LMU540HV 60 208 - 230 187 - 253 29.4 40 1 18.5 2 x 0.12 0.73 x 2 4.8
5.0 LMU600HV 60 208 - 230 187 - 253 32.2 45 1 20.4 2 x 0.12 0.73 x 2 5.2
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
RLA = Rated Load Amps.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as
follows: (Largest motor FLA x 2.25) + (Sum of other motor
FLA) rounded down to the nearest standard fuse size.
Indoor Fan Motor (FLA) is based on the maximum combina-
tion of indoor units.
The max combination for each outdoor unit is:
- 48,000 ODU (LMU480HV): 12,000 IDU x 5
- 54,000 ODU (LMU540HV): 12,000 IDU x 6
- 60,000 ODU (LMU6000HV): 12,000 IDU x 6 + 9,000 IDU
x 1
Table 4: Multi F MAX Electrical Data.
GENERAL DATA
Multi F MAX Outdoor Unit Electrical Data

LG MULTI F MAX Specifications

General

Brand	LG
Model	MULTI F MAX
Category	Air Conditioner
Language	English
