Multi V 5 Cooling Only
4. Indoor Unit and Outdoor Unit Capacity Index
8
General Information
* Capacity Index is same as the capacity(kW).
INDOOR UNIT CAPACITY INDEX
* Capacity Index is same as the capacity(kW).
CAUTION
Combination Ratio(50~200%)
Notes:
1. We can guarantee the operation only within 130% Combination Ratio.
If you want to connect more than 130% combination Ratio, please contact us and discuss the
requirement.
2. In case that operating indoor units ratio to rated capacity of outdoor unit is more than 130%, the airflow
should be operated as low step in the all indoor units.
70 123.1 147.7 172.3 197.0 221.6 246.2 270.8 295.4 320.1 - -
72 126.6 151.9 177.2 202.6 227.9 253.2 278.5 303.8 329.2 - -
74 130.1 156.1 182.1 208.2 234.2 260.2 286.2 312.2 338.3 - -
76 133.7 160.4 187.1 213.8 240.6 267.3 294.0 320.8 347.5 - -
78 137.2 164.6 192.0 219.4 246.9 274.3 301.7 329.2 356.6 - -
80 140.7 168.8 196.9 225.0 253.2 281.3 309.4 337.6 365.7 - -
Unit
Capacity
(Btu/h)
5k 7k 9k 12k 15k 18k 21k 24k 28k 30k 36k 42k 48k 54k 60k 76k 96k
Capacity
Index
1.6 2.2 2.8 3.6 4.5 5.6 6.2 7.1 8.2 9.0 10.6 12.3 14.1 15.8 17.5 22.4 28.0
Number of Outdoor units Combination Ratio
Single Unit 200%
Two Units combination 160%
Three or more Units combination 130%
Outdoor Unit
Capacity(RT)
Indoor Unit Combination Ratio
50% 60% 70% 80% 90% 100% 110% 120% 130% 160% 200%
