LG MULTI V 5 ARUV121BTE5 User Manual

2
Multi V 5 Cooling Only
Outdoor Units
1. Specifications
1.1 220V
RT 8 10
Model Name
Combination Unit ARUV096BTE5 ARUV121BTE5
Independent Unit
ARUV096BTE5 ARUV121BTE5
Capacity
Cooling (Norminal)
Btu/h 96,000 120,000
kW 28.1 35.2
Cooling (Rated)
Btu/h 92,000 114,000
kW 27.0 33.4
Input
Cooling (Norminal) kW 5.90 8.51
Cooling (Rated) kW 5.49 7.86
EER (Norminal) 4.76 4.14
EER (Rated) 4.92 4.25
Power Factor Rated - 0.93 0.93
Exterior
Color Morning Gray / Dawn Gray Morning Gray / Dawn Gray
RAL (Classic) RAL 7030 / RAL 7037 RAL 7030 / RAL 7037
Heat Exchanger Wide Louver Plus Wide Louver Plus
Compressor
Type Hermetically Sealed Scroll Hermetically Sealed Scroll
Piston Displacement
cm
3
/rev
62.1 62.1
Number of Revolution rev/min 3,600 3,600
Motor Output x Number W x No. 5,300 × 1 5,300 × 1
Starting Method Inverter Inverter
Oil Type FVC68D(PVE) FVC68D(PVE)
Fan
Type Propeller fan Propeller fan
Motor Output x Number W 1,200 × 1 1,200 × 1
Air Flow Rate(High)
m
3
/min
240 × 1 240 × 1
ft
3
/min
8,476 × 1 8,476 × 1
Drive DC INVERTER DC INVERTER
Discharge Side / Top TOP TOP
Pipe
Connctions
Liquid mm(inch) 9.52(3/8) 12.7(1/2)
Gas mm(inch) 22.2(7/8) 28.58(1-1/8)
Dimensions(W x H x D)
mm (930 × 1,690 × 760) × 1 (930 × 1,690 × 760) × 1
inch (36-5/8 × 66-17/32 × 29-29/32) × 1 (36-5/8 × 66-17/32 × 29-29/32) × 1
Net Weight
kg 188 × 1 188 × 1
lbs 414 × 1 414 × 1
Sound Pressure Level (Cooling) dB(A) 58.0 59.0
Sound Power Level (Cooling) dB(A) 78.0 79.0
Protection
Devices
High pressure protection High pressure sensor / High pressure switch
Compressor/Fan Over-heat protection / Fan driver overload protector
Inverter Over-heat protection / Over-current protection
Communication Cable (VCTF-SB)
No.×㎟
2C × 1.0 ~ 1.5 2C × 1.0 ~ 1.5
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Power factor could vary less than ±1% according to the operating conditions.
4. Sound pressure level is measured on the rated condition in the anechoic rooms by ISO 3745 standard.
Sound power level is measured on the rated condition in the reverberation rooms by ISO 9614 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
5. Sound values of combination model are calculated values based on sound results of independent models.
Sound values can be increased owing to ambient or installation conditions during operation.
Sound values of system [dB(A)] = 10*log [10^(A1/10)+ ... +10^(An/10)] , A1~An means sound values of independent models.
6. Performances are based on the following conditions :
• *Cooling : Indoor Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• Interconnected Pipe Length is 7.5m and difference of Elevation (Outdoor ~ Indoor Unit) is 0m.
7. *** : The number in parentheses means maximum connectable indoor units in accordance with outdoor units combination (160~200%).
The recommended ratio is 130%.
8. This product contains Fluorinated greenhouse gases.(R410A, GWP(Global warming potential) = 2,087.5)
