LG MULTI V 5 ARUV121BTE5 User Manual

4
Multi V 5 Cooling Only
Installation of Outdoor Units
3. Installation Space
3.1 Individual Installation
During the installation of the unit, consider service, inlet, and outlet and acquire the minimum space as shown in
the figures below. Side space should be more than 49mm(1-15/16inch) for operating of Auto Dust Removal mode.
Category Installation Space
Case 1 [Unit : mm(inch)]
(10(13/32) ˺ Side Space ˺ 49(1-15/16))
Case 2 [Unit : mm(inch)]
(Side Space ˻ 49(1-15/16))
4 sides are
walls
A ˻ 10(13/32)
B ˻ 300(11-13/16)
C ˻ 10(31/32)
D ˻ 500(19-11/16)
A ˻ 50(1-31/32)
B ˻ 100(3-15/16)
C ˻ 50(1-31/32)
D˻ 500(19-11/16)
A ˻ 10(13/32)
B ˻ 300(11-13/16)
C ˻ 10(13/32)
D ˻ 500(19-11/16)
E ˻ 20(25/32)
A ˻ 50(1-31/32)
B ˻ 100(3-15/16)
C ˻ 50(1-31/32)
D ˻ 500(19-11/16)
E ˻ 100(3-15/16)
A ˻ 10(13/32)
B ˻ 300(11-13/16)
C ˻ 10(31/32)
D ˻ 500(19-11/16)
E ˻ 20(25/32)
F ˻ 600(23-5/8)
A ˻ 50(1-31/32)
B ˻ 100(3-15/16)
C ˻ 50(1-31/32)
D ˻ 500(19-11/16)
E ˻ 100(3-15/16)
F
˻ 500(19-11/16)
A ˻ 10(13/32)
B ˻ 300(11-13/16)
C ˻ 10(31/32)
D ˻ 300(11-13/16)
E ˻ 20(25/32)
F ˻ 500(19-11/16)
A ˻ 50(1-31/32)
B ˻ 100(3-15/16)
C ˻ 50(1-31/32)
D ˻ 100(3-15/16)
E ˻ 100(3-15/16)
F ˻ 500(19-11/16)
Rear to Rear
A ˻ 10(13/32)
B ˻ 500(19-11/16)
C ˻ 10(31/32)
D ˻ 500(19-11/16)
F ˻ 900(35-7/16)
A ˻ 50(1-31/32)
B ˻500
C ˻ 50(1-31/32)
D ˻ 500(19-11/16)
F ˻ 600
A ˻ 10(13/32)
B ˻ 500(19-11/16)
C ˻ 10(31/32)
D ˻ 500(19-11/16)
E ˻ 20(25/32)
F ˻ 1200(47-1/4)
A ˻ 50(1-31/32)
B ˻ 500(19-11/16)
C ˻ 50(1-31/32)
D ˻ 500(19-11/16)
E ˻
100(3-15/16)
F ˻ 900(35-7/16)
A ˻ 10(13/32)
B ˻ 500(19-11/16)
C ˻ 10(31/32)
D ˻ 500(19-11/16)
E ˻ 20(25/32)
F ˻ 1800(70-7/8)
A ˻ 50(1-31/32)
B ˻ 500(19-11/16)
C ˻ 50(1-31/32)
D ˻ 500(19-11/16)
E ˻ 100(3-15/16)
F ˻ 1200(47-1/4)
Front
Front
Front Front
Front Front
Front Front
Front
Front
Front Front
Front Front
Front Front
Front Front Front
Front
