78
Multi V 5 Cooling Only
Outdoor Units
2. Dimensions
ARUV096BTE5 / ARUV121BTE5
ARUV096DTE5 / ARUV121DTE5
Gravity point
System
RT
[mm(inch)]
Gas
Cooling Only
8
10
Liquid
pipe pipe
Ø 9.52 (3/8) Ø 22.2 (7/8)
Ø 12.7 (1/2) Ø 28.58 (1-1/8)
