LG MULTI V 5 ARUV121BTE5 User Manual

Multi V 5 Cooling Only
6. Electric Characteristics
96
Outdoor Units
■ 220V
Model
Unit Power Supply COMP OFM
Hz Volts Voltage-range MCA TOCA MFA MSC RLA(Cooling) kW FLA
8 RT 60 220 Min.:198, Max.:242 35.7 40.0 40 11.0 10.5 1.77 5.0
10 RT 60 220 Min.:198, Max.:242 36.0 40.0 40 11.0 17.2 1.77 5.0
12 RT 60 220 Min.:198, Max.:242 36.4 40.0 50 11.0 19.2 2.84 8.0
14 RT 60 220 Min.:198, Max.:242 53.6 59.0 60 18.8 20.8 2.84 8.0
16 RT 60 220 Min.:198, Max.:242 60.5 69.0 70 21.9 25.4 2.84 8.0
18 RT 60 220 Min.:198, Max.:242 71.4 80.0 90 21.9 33.1 2.84 8.0
20 RT 60 220 Min.:198, Max.:242 72.1 80.0 90 21.9 41.1 2.84 8.0
22 RT 60 220 Min.:198, Max.:242 72.7 80.0 90 21.9 50.7 2.84 8.0
24 RT 60 220 Min.:198, Max.:242 89.7 99.0 100 29.8 38.0 4.61 13.0
26 RT 60 220 Min.:198, Max.:242 96.6 109.0 110 32.9 42.6 4.61 13.0
28 RT 60 220 Min.:198, Max.:242 107.5 120.0 130 32.9 50.2 4.61 13.0
30 RT 60 220 Min.:198, Max.:242 108.1 120.0 130 32.9 58.3 4.61 13.0
32 RT 60 220 Min.:198, Max.:242 108.4 120.0 140 32.9 60.3 5.67 16.0
34 RT 60 220 Min.:198, Max.:242 125.7 139.0 150 40.7 61.9 5.67 16.0
36 RT 60 220 Min.:198, Max.:242 132.6 149.0 160 43.8 66.5 5.67 16.0
38 RT 60 220 Min.:198, Max.:242 143.5 160.0 180 43.8 74.2 5.67 16.0
40 RT 60 220 Min.:198, Max.:242 144.1 160.0 180 43.8 82.2 5.67 16.0
42 RT 60 220 Min.:198, Max.:242 144.5 160.0 180 43.8 77.5 7.44 21.0
44 RT 60 220 Min.:198, Max.:242 161.7 179.0 190 51.7 79.1 7.44 21.0
46 RT 60 220 Min.:198, Max.:242 168.6 189.0 200 54.8 83.7 7.44 21.0
48 RT 60 220 Min.:198, Max.:242 179.5 200.0 220 54.8 91.3 7.44 21.0
50 RT 60 220 Min.:198, Max.:242 180.2 200.0 220 54.8 99.4 7.44 21.0
52 RT 60 220 Min.:198, Max.:242 180.5 200.0 230 54.8 101.4 8.51 24.0
54 RT 60 220 Min.:198, Max.:242 197.8 219.0 240 62.6 103.0 8.51 24.0
56 RT 60 220 Min.:198, Max.:242 204.7 229.0 250 65.7 107.6 8.51 24.0
58 RT 60 220 Min.:198, Max.:242 215.6 240.0 270 65.7 115.3 8.51 24.0
60 RT 60 220 Min.:198, Max.:242 216.2 240.0 270 65.7 123.3 8.51 24.0
62 RT 60 220 Min.:198, Max.:242 216.5 240.0 270 65.7 118.6 10.28 29.0
64 RT 60 220 Min.:198, Max.:242 234.1 259.0 290 73.6 120.2 11.34 32.0
66 RT 60 220 Min.:198, Max.:242 240.7 269.0 290 76.7 124.8 10.28 29.0
68 RT 60 220 Min.:198, Max.:242 251.6 280.0 310 76.7 132.4 10.28 29.0
70 RT 60 220 Min.:198, Max.:242 252.3 280.0 310 76.7 140.5 10.28 29.0
72 RT 60 220 Min.:198, Max.:242 252.6 280.0 320 76.7 142.5 11.34 32.0
74 RT 60 220 Min.:198, Max.:242 269.9 299.0 330 84.5 144.1 11.34 32.0
76 RT 60 220 Min.:198, Max.:242 276.7 309.0 340 87.6 148.7 11.34 32.0
78 RT 60 220 Min.:198, Max.:242 287.6 320.0 360 87.6 156.4 11.34 32.0
80 RT 60 220 Min.:198, Max.:242 288.3 320.0 360 87.6 164.4 11.34 32.0
Note
1. Voltage supplied to the unit terminals should be within the minimum and maximum range.
2. Maximum allowable voltage unbalance between phase is 2%.
3. MSC means the Max. current during the starting of compressor.
4. MSC and RLA are measured as the compressor only test condition.
5. OFM are measured as the outdoor unit test condition.
6. TOCA means the total over current value of each outdoor unit.
7. Select the wire size based on the larger value among MCA or TOCA.
8. MFA is recommended fuse amps.
9. TOCA is minimum required amperes for selecting the circuit breaker and ground fault circuit
interrupter. Please select the circuit breaker size equal or greater than TOCA.
All installation site must require attachment of an earth leakage breaker.[Circuit breaker type is
ELCB (Earth Leakage Circuit Breaker)].
10.Select the electrical equipment of combination unit according to the electrical characteristics of
individual unit.
Symbols
MCA : Minimum Circuit Amperes (A)
TOCA : Total Over Current Amperes
(A)
MFA : Maximum Fuse Amperes (A)
MSC : Maximum Starting Current (A)
RLA : Rated Load Amperes (A)
OFM : Outdoor Fan Motor
kW : Fan Motor rated output (kW)
FLA : Full Load Amperes (A)
