Drain pan heater options
Table 1 lists the drain pan heater models and the corresponding Multi V 5 Outdoor Unit model numbers.
Model Number Multi V 5 ODU Model Tonnage Wattage Voltage Amps Fuse
ZPLT1A51A ARUM072BTE5 6 498 208/230 2.39 KTK-3
ZPLT2A51A ARUM072DTE5 6 633 460 1.38 KTK-1 1/2
ZPLT1A52A ARUM096BTE5 8 599 208/230 2.88 KTK-3
ZPLT2A52A ARUM096DTE5 8 761 460 1.65 KTK-2
ZPLT1A52A ARUM121BTE5 10 599 208/230 2.88 KTK-3
ZPLT2A52A ARUM121DTE5 10 761 460 1.65 KTK-2
ZPLT1A52A ARUM144BTE5 12 599 208/230 2.88 KTK-3
ZPLT2A52A ARUM144DTE5 12 761 460 1.65 KTK-2
ZPLT1A52A ARUM168BTE5 14 599 208/230 2.88 KTK-3
ZPLT2A52A ARUM168DTE5 14 761 460 1.65 KTK-2
ZPLT1A52A ARUM192BTE5 16 599 208/230 2.88 KTK-3
ZPLT2A52A ARUM192DTE5 16 761 460 1.65 KTK-2
ZPLT1A52A ARUM216BTE5 18 599 208/230 2.88 KTK-3
ZPLT2A52A ARUM216DTE5 18 761 460 1.65 KTK-2
ZPLT1A52A ARUM241BTE5 20 599 208/230 2.88 KTK-3
ZPLT2A52A ARUM241DTE5 20 761 460 1.65 KTK-2
Table 1: Drain Pan Heater options and corresponding Multi V 5 ODU models.
DRAIN PAN HEATER OPTIONS

LG Multi V 5 Specifications

General

Type	VRF (Variable Refrigerant Flow)
Refrigerant	R410A
Compressor Type	Inverter Scroll Compressor
Outdoor Unit Fan Type	Axial Fan
Cooling Capacity	22.4 kW to 270 kW
Energy Efficiency	High
Operating Range	Cooling: -5°C to 48°C
Power Supply	380-415V, 50/60Hz
Heat Exchanger Type	Microchannel
Control Type	Centralized Control
Indoor Unit Options	Cassette, Wall Mounted, Ducted
Heat Recovery	Available
Warranty	Varies by region (typically 5 years compressor, 1-2 years parts)
