- 6 -
Copyright © 2018 LG Electronics Inc.
All rights reserved. Only training and service purposes.
Type Ceiling Concealed Duct -Middle Static
Model Unit ARNU483M3A4 ARNU543M3A4
Cooling Capacity
kW
kcal/h
Btu/h
Heating Capacity
kW
kcal/h
Btu/h
Power Input
Nominal W
Rated W
Casing
Dimensions (WxHxD) Body
mm
inch
Coil
Rows x Columns x FPI
Face Area m
2
(ft
2
)
Fan
Type
Motor Output x Number W
Running Current A
Air Flow Rate(H / M / L)
(High Mode-Factory Set)
External static pressure
CMM
CFM
mmAq(Pa)
Air Flow Rate(H / M / L)
(Standard mode)
External static Pressure
CMM
CFM
mmAq(Pa)
Drive
Motor type
Temperature Control
Sound Absorbing Thermal Insulation Material
Air Filter
Safety Device
Pipe Connections
Liquid Side mm(inch)
Gas Side mm(inch)
Drain Pipe(Internal Dia.) mm(inch)
Net Weight Body kg(lbs)
Sound Pressure Levels (H / M / L) dB(A)
Sound Power Levels (H / M / L) dB(A)
Power Supply Ø, V, Hz
Refrigerant Control
Transmission Cable (AWG# -C)
14.1
12 100
48 100
15.9
13 600
54 200
172
650
Galvanized Steel Plate
1 250 × 360 × 700
49-7/32 x 14-3/16 x 27-9/16
3 x 16 x 18
0.32(3.44)
Sirocco Fan
500 x 1
2.5
40.0 / 34.0 / 28.0
1 413 / 1 201 / 989
6(59)
40.0 / 34.0 / 28.0
1 413 / 1 201 / 989
5(49)
Direct
BLDC
Microprocessor, Thermostat for
cooling and heating
Foamed polystyrene
-
Fuse
Ø9.52(3/8)
Ø15.88(5/8)
25(1)
43.6(96)
42 / 39 / 37
67 / 64 / 62
1, 208-230, 60
EEV
AWG 18 x 2C
15.8
13 600
54 000
18
15 500
61 400
260
650
Galvanized Steel Plate
1 250 × 360 × 700
49-7/32 x 14-3/16 x 27-9/16
3 x 16 x 18
0.32(3.44)
Sirocco Fan
500 x 1
2.5
50.0 / 45.0 / 40.0
1 766 / 1 589 / 1 413
6(59)
50.0 / 45.0 / 40.0
1 766 / 1 589 / 1 413
5(49)
Direct
BLDC
Microprocessor, Thermostat for
cooling and heating
Foamed polystyrene
-
Fuse
Ø9.52(3/8)
Ø15.88(5/8)
25(1)
43.6(96)
44 / 43 / 42
69 / 68 / 67
1, 208-230, 60
EEV
AWG 18 x 2C
Notes:-
1. Capacities are based on the following conditions:
Cooling • Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
• Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
• Interconnecting Piping Length 7.5m(24.6ft)
• Level Difference of Zero
Heating • Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
• Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
• Interconnecting Piping Length 7.5m(24.6ft)
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without prior notification
4. To be added for more available Models
5. EEV : Electronic Expansion Valve
6. Noise Level is Standard Mode
(for actual High Mode(factory set) condition, Noise Level may exceed the standard level by 1.5dBA)
Conversion Formula
kcal/h= kW x 860
Btu/h = kW x 3412
CFM = m
3
/min x 35.3
l/s = CMM x 1 000/60
