4.14 Vacuum Mode
This function is used for creating vacuum in the system after compressor replacement, ODU parts replacement
or IDU addition/replacement.
4.15 Static pressure compensation mode
This function is used for creating vacuum in the system after compressor replacement, ODU parts replacement
or IDU addition/replacement.
Function
Master unit PCB DIP switch on : No.5
Start the vacuum mode : “VACC”
ODU V/V open
ODU EEV open
IDU EEV open
Vacuum mode setting method
Vacuum mode cancellation method
Push the reset button on Master unit PCB
Select the mode using
ȯ, ȭ Button : “SVC”
Push the button
Select the Function using ȯ, ȭ Button : : “Se3”
Push the button
Master unit PCB DIP switch on : No.5
Select the mode usingȯ’, ‘ȭButton : “Func”
Push the button
Select the Function using ȯ’, ‘ȭButton : “Fn2”
Push the button
Select the Option using
ȯ’, ‘ȭButton : : “op1~op3”
Push the button
Start the Static pressure compensation mode :
Save the selected option value in EEPROM
CAUTION
ODU operation stops during vacuum mode. Compressor can't operate.
FAN Maximum RPM of each step
Static pressure compensation mode setting method
Capacity
8~12HP 14~20HP
Max. RPM
Standard 730 950
Step1 760 1020
Step2 780 1050
Step3 800 1130
Function
