4.17 Cycle Data View
This function is intended to identify the Cycle data of ODU, which is running on.
The 7 Segment is display 26 different cycle data.
Master unit PCB DIP switch on : No.5
Cycle data view function setting method
Select the mode using ‘ȯ’, ‘ȭ’ Button : “SVC”
Push the ‘●’ button
Select the Function using ‘ȯ’, ‘ȭ’ Button : : “Se3”
Push the
‘●’ button
Selec the Option using ‘ȯ’, ‘ȭ’ Button : : “op1~op26”
Push the ‘●’ button
Start the Cyce data view fuction : Display the cycle
data value selected from the Segment.
step Title 7-seg example seg_1 seg_2 seg_3 seg_4
op1 Current High Pressure P1 4321kPa 4 3 2 1
op2 Current low Pressure P2 1234kPa 1 2 3 4
op3 Inv 1 Pulse h1 120 1 2 0
op4 Inv 2 Pulse h2 30 3 0
op5 fan rpm h3 110 1 1 0
op6 Subcooling degree T1 5.3 5 3
op7 Superheating degree T2 -4.5 - 4 5
op8 ODU temp. T3 10 1 0 0
op9 Suctino temp. T4 43.4 4 3 4
op10 Comp1 discharge temp. T5 150 1 5 0
op11 Comp2 discharge temp. T6 124 1 2 4
op12 Liquid pipe temp. T7 10 1 0 0
op13 Sc_in T8 10 1 0 0
op14 Sc_out T9 10 1 0 0
op15 hex_total T10 10 1 0 0
op16 hex_hi T11 10 1 0 0
op17 hex_low T12 10 1 0 0
op18 Inlet pipe temp of IDU T13 -10° - 1 0 0
op19 main1 eev PLS1 1940 1 9 4 0
op20 main2 eev PLS2 32 3 2
op21 sc eev PLS3 16 1 6
op22 oil eev PLS4 50 5 0
op23 vi eev 1 PLS5 1350 1 3 5 0
op24 vi eev 2 PLS6 8 8
op25 IDU running capacity IDU1 24k 2 4
op26 Total number of IDU IDU2 10 1 0
