- 52 -
Copyright ©2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
n
Location of setting Switch
3. DIP Switch Setting
DIP-SW01 7 - Segment
SW04C (X : cancel)
SW03C (ȯ : forward)
SW02C (ȭ : backward)
SW01C (Ɨ : confirm)
SW01D (reset)
Heat Pump (Main PCB)
Test Run
