40 | PERFORMANCE DATA
MULTI V S Three-Phase Outdoor Unit Engineering Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
THREE-PHASE
HEATING CAPACITY DATA
96,000 Btu/h 208-230V Three-Phase Outdoor Units
ARUN096BSS5
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
Combination
(%)
Outdoor air
temp.
Indoor Air Temp. °F DB
59 61 64 67 70 73 76 80
°F DB °F WB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC Pl
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
70
-12.6 -13.0 72.4 9.40 72.1 9.63 71.7 9.96 71.3 10.81 71.0 11.65 69.6 11.60 67.4 11.59 64.4 11.56
-7.0 -7.6 82.7 10.41 82.7 10.64 82.6 10.97 78.8 11.29 75.1 11.60 71.0 11.57 66.9 11.55 61.5 11.53
-4.0 -4.4 90.0 11.02 87.0 11.24 82.6 11.58 78.8 11.58 75.1 11.58 71.0 11.55 66.9 11.53 61.5 11.52
0.0 -0.4 90.8 11.64 87.5 11.62 82.6 11.59 78.8 11.57 75.1 11.55 71.0 11.23 66.9 11.04 61.5 10.79
5.0 4.5 90.8 11.57 87.5 11.55 82.6 11.50 78.8 11.33 75.1 11.15 71.0 10.63 66.9 10.43 61.5 10.17
10.0 9.0 90.8 11.51 87.5 11.47 82.6 11.42 78.8 10.98 75.1 10.53 71.0 10.04 66.9 9.82 61.5 9.54
15.0 14.0 90.8 11.66 87.5 11.33 82.6 10.84 78.8 10.38 75.1 9.92 71.0 9.45 66.9 9.22 61.5 8.92
20.0 19.0 90.8 10.90 87.5 10.59 82.6 10.14 78.8 9.71 75.1 9.29 71.0 8.84 66.9 8.60 61.5 8.28
25.0 23.0 90.8 10.15 87.5 9.87 82.6 9.45 78.8 9.06 75.1 8.67 71.0 8.24 66.9 7.99 61.5 7.66
30.0 28.0 90.8 9.40 87.5 9.15 82.6 8.76 78.8 8.40 75.1 8.05 71.0 7.65 66.9 7.38 61.5 7.03
35.0 32.0 90.8 8.66 87.5 8.42 82.6 8.07 78.8 7.75 75.1 7.42 71.0 7.05 66.9 6.77 61.5 6.40
40.0 36.0 90.8 7.91 87.5 7.70 82.6 7.38 78.8 7.09 75.1 6.80 71.0 6.45 66.9 6.16 61.5 5.78
45.0 41.0 90.8 7.18 87.5 7.00 82.6 6.72 78.8 6.46 75.1 6.20 71.0 5.87 66.9 5.57 61.5 5.17
47.0 43.0 90.8 6.99 87.5 6.81 82.6 6.54 78.8 6.28 75.1 6.03 71.0 5.71 66.9 5.42 61.5 5.03
50.0 46.0 90.8 6.74 87.5 6.56 82.6 6.30 78.8 6.05 75.1 5.81 71.0 5.50 66.9 5.22 61.5 4.85
55.0 51.0 90.8 6.32 87.5 6.16 82.6 5.91 78.8 5.68 75.1 5.45 71.0 5.17 66.9 4.90 61.5 4.55
60.0 56.0 90.8 5.88 87.5 5.73 82.6 5.50 78.8 5.28 75.1 5.07 71.0 4.80 66.9 4.56 61.5 4.23
60
-12.6 -13.0 67.2 8.80 66.8 9.02 66.1 9.36 65.3 10.20 64.4 11.04 60.6 10.99 57.3 10.97 52.9 10.93
-7.0 -7.6 77.7 9.81 75.1 10.03 71.1 10.37 67.7 10.68 64.4 10.99 60.6 10.95 57.3 10.93 52.9 10.90
-4.0 -4.4 77.7 10.41 75.1 10.64 71.1 10.97 67.7 10.96 64.4 10.96 60.6 10.79 57.3 10.46 52.9 10.03
0.0 -0.4 77.7 11.04 75.1 11.02 71.1 11.00 67.7 10.86 64.4 10.71 60.6 10.33 57.3 9.98 52.9 9.51
5.0 4.5 77.7 11.00 75.1 10.98 71.1 10.96 67.7 10.53 64.4 10.11 60.6 9.73 57.3 9.39 52.9 8.93
10.0 9.0 77.7 11.19 75.1 10.94 71.1 10.57 67.7 10.04 64.4 9.51 60.6 9.14 57.3 8.80 52.9 8.34
15.0 14.0 77.7 10.67 75.1 10.36 71.1 9.90 67.7 9.41 64.4 8.92 60.6 8.55 57.3 8.22 52.9 7.77
20.0 19.0 77.7 9.95 75.1 9.65 71.1 9.20 67.7 8.76 64.4 8.31 60.6 7.94 57.3 7.61 52.9 7.17
25.0 23.0 77.7 9.25 75.1 8.96 71.1 8.52 67.7 8.12 64.4 7.71 60.6 7.34 57.3 7.02 52.9 6.59
30.0 28.0 77.7 8.55 75.1 8.27 71.1 7.84 67.7 7.47 64.4 7.11 60.6 6.74 57.3 6.43 52.9 6.00
35.0 32.0 77.7 7.85 75.1 7.57 71.1 7.16 67.7 6.83 64.4 6.51 60.6 6.15 57.3 5.83 52.9 5.42
40.0 36.0 77.7 7.15 75.1 6.88 71.1 6.47 67.7 6.19 64.4 5.91 60.6 5.55 57.3 5.24 52.9 4.83
45.0 41.0 77.7 6.47 75.1 6.21 71.1 5.81 67.7 5.57 64.4 5.33 60.6 4.97 57.3 4.67 52.9 4.27
47.0 43.0 77.7 6.30 75.1 6.04 71.1 5.66 67.7 5.42 64.4 5.19 60.6 4.84 57.3 4.55 52.9 4.16
50.0 46.0 77.7 6.06 75.1 5.82 71.1 5.45 67.7 5.22 64.4 4.99 60.6 4.66 57.3 4.38 52.9 4.01
55.0 51.0 77.7 5.69 75.1 5.46 71.1 5.12 67.7 4.90 64.4 4.69 60.6 4.37 57.3 4.11 52.9 3.76
60.0 56.0 77.7 5.29 75.1 5.08 71.1 4.76 67.7 4.56 64.4 4.36 60.6 4.07 57.3 3.82 52.9 3.50
50
-12.6 -13.0 65.0 7.79 62.6 8.01 59.1 8.35 56.4 9.19 53.8 10.03 50.6 9.97 47.6 9.92 43.7 9.86
-7.0 -7.6 65.0 8.80 62.6 9.02 59.1 9.36 56.4 9.66 53.8 9.97 50.6 9.71 47.6 9.24 43.7 8.61
-4.0 -4.4 65.0 9.40 62.6 9.63 59.1 9.96 56.4 9.95 53.8 9.94 50.6 9.36 47.6 8.90 43.7 8.29
0.0 -0.4 65.0 10.04 62.6 10.01 59.1 9.97 56.4 9.74 53.8 9.51 50.6 8.92 47.6 8.48 43.7 7.90
5.0 4.5 65.0 10.22 62.6 9.96 59.1 9.56 56.4 9.24 53.8 8.93 50.6 8.38 47.6 7.96 43.7 7.41
10.0 9.0 65.0 10.01 62.6 9.58 59.1 8.95 56.4 8.65 53.8 8.34 50.6 7.84 47.6 7.44 43.7 6.92
15.0 14.0 65.0 9.33 62.6 8.94 59.1 8.35 56.4 8.06 53.8 7.77 50.6 7.30 47.6 6.93 43.7 6.44
20.0 19.0 65.0 8.63 62.6 8.27 59.1 7.72 56.4 7.45 53.8 7.18 50.6 6.75 47.6 6.40 43.7 5.94
25.0 23.0 65.0 7.94 62.6 7.61 59.1 7.11 56.4 6.85 53.8 6.60 50.6 6.20 47.6 5.88 43.7 5.45
30.0 28.0 65.0 7.26 62.6 6.95 59.1 6.50 56.4 6.26 53.8 6.01 50.6 5.66 47.6 5.36 43.7 4.96
35.0 32.0 65.0 6.57 62.6 6.30 59.1 5.89 56.4 5.66 53.8 5.43 50.6 5.11 47.6 4.84 43.7 4.47
40.0 36.0 65.0 5.88 62.6 5.64 59.1 5.28 56.4 5.06 53.8 4.85 50.6 4.57 47.6 4.32 43.7 3.98
45.0 41.0 65.0 5.22 62.6 5.01 59.1 4.69 56.4 4.49 53.8 4.29 50.6 4.05 47.6 3.82 43.7 3.51
47.0 43.0 65.0 5.08 62.6 4.87 59.1 4.56 56.4 4.37 53.8 4.18 50.6 3.94 47.6 3.71 43.7 3.41
50.0 46.0 65.0 4.89 62.6 4.69 59.1 4.40 56.4 4.21 53.8 4.02 50.6 3.80 47.6 3.58 43.7 3.29
55.0 51.0 65.0 4.59 62.6 4.41 59.1 4.13 56.4 3.95 53.8 3.77 50.6 3.56 47.6 3.36 43.7 3.09
60.0 56.0 65.0 4.27 62.6 4.10 59.1 3.84 56.4 3.67 53.8 3.51 50.6 3.31 47.6 3.12 43.7 2.87
