PERFORMANCE DATA | 41
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
THREE-PHASE
72,000 Btu/h and 96,000 Btu/h 208-230V 3-Phase Outdoor Units
ARUN072BSS5 and ARUN096BSS5
MAXIMUM HEATING CAPACITY DATA
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
The System Combination Ratio must be between 50–130%.
Capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Maximum capacity based on full-load (maximum) compressor operation rather than part-load operation
as published in nominal capacity tables.
Combination
(%)
Outdoor air
temp.
Indoor Air Temp. °F DB
59 61 64 67 70 73 76 80
°F DB °F WB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC Pl
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
100
-12.6 -13.0 63.7 9.07 63.2 9.26 62.3 9.53 62.4 10.00 62.6 10.46 62.1 10.81 61.7 10.95 61.3 11.14
-7.0 -7.6 71.6 9.48 71.3 9.66 70.8 9.94 70.5 10.34 70.2 10.74 69.6 10.96 69.3 11.05 65.8 10.70
-4.0 -4.4 76.5 9.73 76.2 9.91 75.7 10.18 75.2 10.55 74.8 10.91 73.4 10.89 71.4 10.62 65.8 10.26
0.0 -0.4 82.3 10.04 81.9 10.21 81.4 10.48 80.4 10.66 79.4 10.83 76.0 10.50 71.8 10.20 65.8 9.79
5.0 4.5 88.2 10.56 87.7 10.68 86.9 10.85 84.0 10.58 81.0 10.31 76.2 9.97 71.8 9.68 65.8 9.29
10.0 9.0 96.3 10.75 93.4 11.00 89.0 10.71 85.0 10.24 81.0 9.78 76.2 9.44 71.8 9.16 65.8 8.80
15.0 14.0 98.0 10.76 94.4 10.50 89.0 10.11 85.0 9.69 81.0 9.26 76.2 8.92 71.8 8.66 65.8 8.31
20.0 19.0 98.0 10.10 94.4 9.86 89.0 9.50 85.0 9.11 81.0 8.73 76.2 8.38 71.8 8.13 65.8 7.80
25.0 23.0 98.0 9.44 94.4 9.22 89.0 8.89 85.0 8.55 81.0 8.20 76.2 7.85 71.8 7.62 65.8 7.30
30.0 28.0 98.0 8.79 94.4 8.59 89.0 8.29 85.0 7.98 81.0 7.67 76.2 7.33 71.8 7.10 65.8 6.80
35.0 32.0 98.0 8.13 94.4 7.95 89.0 7.69 85.0 7.42 81.0 7.15 76.2 6.80 71.8 6.59 65.8 6.30
40.0 36.0 98.0 7.48 94.4 7.32 89.0 7.08 85.0 6.85 81.0 6.62 76.2 6.27 71.8 6.07 65.8 5.80
45.0 41.0 98.0 6.84 94.4 6.70 89.0 6.49 85.0 6.30 81.0 6.10 76.2 5.75 71.8 5.57 65.8 5.32
47.0 43.0 98.0 6.66 94.4 6.52 89.0 6.32 85.0 6.13 81.0 5.94 76.2 5.60 71.8 5.42 65.8 5.18
50.0 46.0 98.0 6.41 94.4 6.28 89.0 6.09 85.0 5.90 81.0 5.72 76.2 5.39 71.8 5.22 65.8 4.99
55.0 51.0 98.0 6.02 94.4 5.90 89.0 5.71 85.0 5.54 81.0 5.37 76.2 5.06 71.8 4.90 65.8 4.68
60.0 56.0 98.0 5.60 94.4 5.48 89.0 5.31 85.0 5.15 81.0 4.99 76.2 4.71 71.8 4.55 65.8 4.35
Table 5: ARUN072BSS5 Maximum Heating Capacity.
Table 6: ARUN096BSS5 Maximum Heating Capacity.
Combination
(%)
Outdoor air
temp.
Indoor Air Temp. °F DB
59 61 64 67 70 73 76 80
°F DB °F WB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI TC Pl
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
100
-12.6 -13.0 85.0 13.97 84.2 14.26 83.1 14.68 83.2 15.40 83.4 16.11 82.7 16.65 82.3 16.87 81.8 17.16
-7.0 -7.6 95.4 14.61 95.0 14.89 94.5 15.31 94.0 15.93 93.6 16.55 92.8 16.88 92.4 17.03 87.8 16.48
-4.0 -4.4 102.0 14.99 101.5 15.27 100.9 15.68 100.3 16.25 99.7 16.81 97.9 16.78 95.2 16.36 87.8 15.80
0.0 -0.4 109.7 15.46 109.2 15.73 108.6 16.14 107.2 16.42 105.8 16.69 101.3 16.17 95.7 15.71 87.8 15.09
5.0 4.5 117.6 16.26 116.9 16.45 115.9 16.72 112.0 16.30 108.0 15.88 101.7 15.36 95.7 14.91 87.8 14.32
10.0 9.0 128.4 16.56 124.5 16.95 118.7 16.49 113.4 15.78 108.0 15.07 101.7 14.54 95.7 14.12 87.8 13.55
15.0 14.0 130.6 16.58 125.9 16.18 118.7 15.58 113.4 14.93 108.0 14.27 101.7 13.74 95.7 13.34 87.8 12.80
20.0 19.0 130.6 15.55 125.9 15.18 118.7 14.63 113.4 14.04 108.0 13.44 101.7 12.91 95.7 12.53 87.8 12.01
25.0 23.0 130.6 14.54 125.9 14.21 118.7 13.70 113.4 13.17 108.0 12.63 101.7 12.10 95.7 11.73 87.8 11.25
30.0 28.0 130.6 13.54 125.9 13.23 118.7 12.77 113.4 12.29 108.0 11.82 101.7 11.28 95.7 10.94 87.8 10.48
35.0 32.0 130.6 12.53 125.9 12.25 118.7 11.84 113.4 11.42 108.0 11.01 101.7 10.47 95.7 10.14 87.8 9.71
40.0 36.0 130.6 11.52 125.9 11.28 118.7 10.91 113.4 10.55 108.0 10.20 101.7 9.66 95.7 9.35 87.8 8.94
45.0 41.0 130.6 10.54 125.9 10.32 118.7 10.00 113.4 9.70 108.0 9.40 101.7 8.86 95.7 8.57 87.8 8.19
47.0 43.0 130.6 10.26 125.9 10.05 118.7 9.73 113.4 9.44 108.0 9.15 101.7 8.62 95.7 8.35 87.8 7.97
50.0 46.0 130.6 9.88 125.9 9.68 118.7 9.37 113.4 9.09 108.0 8.81 101.7 8.31 95.7 8.04 87.8 7.68
55.0 51.0 130.6 9.27 125.9 9.08 118.7 8.80 113.4 8.54 108.0 8.27 101.7 7.80 95.7 7.54 87.8 7.21
60.0 56.0 130.6 8.62 125.9 8.45 118.7 8.18 113.4 7.94 108.0 7.69 101.7 7.25 95.7 7.02 87.8 6.70
