Appendix 23
Appendix
5
Specifications
General (NB3535A)
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D) 950 mm x 71 mm x 47 mm
Net Weight (Approx.) 2.5 kg
Operating temperature 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) 5 V
0
500 mA
Inputs
DIGITAL IN (OPTICAL IN) 3.0 V (p-p), Optical jack x 2
PORT. IN 0.5 Vrms (3.5 mm stereo jack)
Amplier
Stereo mode 80 W + 80 W (4 Ω at 1 kHz), THD 10%
Subwoofer 140 W (3 Ω at 60 Hz), THD 10%
Wireless subwoofer (S33A1-D)
Power requirements Refer to the main label on the subwoofer.
Power consumption Refer to the main label on the subwoofer.
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 140 W
Max. Input Power 280 W
Dimensions (W x H x D) 170 mm x 360 mm x 316 mm
Net Weight 5.54 kg
y
Designs and specications are subject to change without prior notice.
