LG OLED C1 User Manual

9
Wall Mounting Bracket
(Depending on model)
Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in the
following table.
A
B
Model
OLED48/55/65A1*
OLED55/65B1*
OLED48/55/65C1*
OLED77A1*
OLED77B1*
OLED77C1*
OLED83C1*
VESA (A x B) (mm) 300 x 200 400 x 200 400 x 400
Standard screw M6 M6 M6
Number of screws 4 4 4
Wall mount bracket OLW480B OLW480B LSW440B
A
B
Model OLED83C1*
Screws distance (A x B) (mm) 180 x 55
Wall mount bracket WB21EB
Antenna/Cable
Connect the TV to a wall antenna socket with an RF cable (75Ω).
• Use a signal splitter to use more than 2 TVs.
• If the image quality is poor, install a signal amplifier properly to improve the image quality.
• If the image quality is poor with an antenna connected, try to realign the antenna in the correct direction.
• An antenna cable and converter are not supplied.
• For a location that is not supported with Ultra HD broadcasting, this TV cannot receive Ultra HD broadcasts directly.
Satellite dish
Connect the TV to a satellite dish to a satellite socket with a satellite RF cable (75Ω). (Depending on model)

LG OLED C1 Specifications

General

Display Type	OLED
Screen Sizes	48", 55", 65", 77", 83"
Refresh Rate	120 Hz
Processor	α9 Gen4 AI Processor 4K
Operating System	webOS
HDMI Ports	4 (HDMI 2.1)
VRR	Yes
ALLM	Yes
G-Sync Compatible	Yes
FreeSync	Yes
USB Ports	3
Ethernet	Yes
Voice Assistants	Google Assistant, Amazon Alexa
Resolution	4K (3840 x 2160)
HDR	HDR10, HLG, Dolby Vision
Audio	40W (2.2 Channel)
Bluetooth	Yes (Bluetooth 5.0)
Wi-Fi	Yes (Wi-Fi 802.11ac)
