LG OLED48C1PVB

- 21 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
(3) Assemble/Fix the SUPPORTER + MODULE
[Self/Successive Check]
1. [Visual Check] Check the SUPPORTER fix condition.
(4) Assemble/Fix the SUPPORTER + MODULE
[Self/Successive Check]
1.[Visual Check] Check the SUPPORTER fix condition.
2
2
2
2
1
1
1
1
Assemble the
screw after insert
ⓐ→ⓑ
ⓐ
ⓑ
1
3
3
3
Check the sponge on Supporter, Stand Guide when assembly
B8/C8
B9/C9/ET96/CX9/BX9
3
PLATE
SCREW,MACHINE
BRH + 3MM 5.5MM SWCH18A FZMW N
PRESS HGI 1.6T SUPPORTER HGI E
No
Description Qty
①
②
1
4
Specification
SUPPORTER,VESA
SCREW,MACHINE
BRH + 3MM 5.5MM SWCH18A FZMW N
PRESS EGI 1.6 SUPPORTER EGI 32
No
Description Qty
①
②
4
4
Specification
