Connections
Connect various external devices to the TV and switch input modes to select
an external device. For more information of external device’s connection, refer
to the manual provided with each device.
HDMI
• When connecting the HDMI cable, the product and external devices
should be turned off and unplugged.
• Supported HDMI Audio format (Depending on model):
True HD (48kHz),
Dolby Digital / Dolby Digital Plus (32kHz, 44.1kHz, 48kHz),
PCM (32kHz, 44.1kHz, 48kHz, 96kHz, 192kHz)
DTS (44.1kHz / 48kHz / 88.2kHz / 96kHz)
DTS-HD (44.1kHz / 48kHz / 88.2kHz / 96kHz / 176.4kHz / 192kHz)
Note
• If the device connected to Input Port also supports HDMI Deep Colour,
your picture may be clearer. However, if the device doesn’t support it, it
may not work properly. In that case, change the TV’s [HDMI Deep Colour]
setting to off.
•
→ [ ] → [General] → [External Devices] → [HDMI Settings]
→ [HDMI Deep Colour]
• Use a certified cable with the HDMI logo attached.
• If you do not use a certified HDMI cable, the screen may not display or a
connection error may occur.
• Recommended HDMI Cable Types
- Ultra High Speed HDMI
®
/™ cable (3m or less)
USB
Some USB Hubs may not work. If a USB device connected using a USB Hub is
not detected, connect it to the USB port on the TV directly.
Note
• For an optimal connection, HDMI cables and USB devices should have
bezels less than 10mm thick and 18mm width. Use an extension cable
that supports
if the USB cable or USB memory stick does not fit
into your TV’s USB port.
IR Blaster
Control the set-top box (cable/satellite/IP/OTT), Blu-ray/DVD player,
soundbar, game consoles, etc., using the IR Blaster. (Depending on country)
(Depending on models)
Note
• Connect the IR Blaster cable to the TV’s IR Blaster port.
• Use universal control settings to control the device.
• Secure the IR Blaster with the 3M tape provided.
External Devices
Available external devices are: Blu-ray player, HD receivers, DVD players, VCRs,
audio systems, USB storage devices, PC, gaming devices, and other external
devices.
Note
• The external device connection may differ from the model.
• In PC mode, there may be noise associated with the resolution, vertical
pattern, contrast or brightness. If noise is present, change the PC output
to another resolution, change the refresh rate to another rate or adjust
the brightness and contrast on the [Picture] menu until the picture is
clear.
• In PC mode, some resolution settings may not work properly depending
on the graphics card.
• If ULTRA HD content is played on your PC, video or audio may become
disrupted intermittently depending on your PC’s performance.
(Depending on model)
• When connecting to a wired LAN, use a CAT 7 cable with high-speed
Internet transmission. (Only when
port is provided.)

LG OLED48C36LA Specifications

General

Stand	Yes
App store	LG Content Store
Picture mode	Vivid, Standard, Eco, Cinema, Sports, Game, Filmmaker, (ISF)Expert(Bright Room), (ISF)Expert(Dark Room)
Country of origin	South Korea
Digital audio out	1
Wall mounting kit	No
USB ports quantity	3
DisplayPorts quantity	0
Headphone connectivity	3.5mm / Bluetooth
Annual energy consumption	91.323 kWh
Tuner type	Analog & digital
Firmware upgradeable via	Auto upgrade wizard, Network, USB
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Dimming type	Pixel Dimming
Game features	Auto Low Latency Mode (ALLM), Game Dashboard, Game Optimizer, HGiG, Variable Refresh Rate (VRR)
Processor cores	4
Audio formats supported	AAC, AC3, AC4, EAC3, HE-AAC, MP2, MP3, PCM, WMA, apt-X
Picture processing technology	LG AI Picture Pro
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Energy efficiency scale	A to G
Power consumption (sleep)	0.5 W
Power consumption (typical)	65.7 W
Package type	Box
Package depth	162 mm
Package width	1373 mm
Package height	735 mm
Package weight	20500 g
Processor	α9 AI Processor 4K Gen6
Sound technology	AI Sound Pro (Virtual 9.1.2 Up-mix)
Sound modes	AI Sound Pro, Clear Voice Pro
Audio decoders	Dolby Atmos
RMS rated power	40 W
Number of speakers	-
Audio output channels	2.2 channels
Cables included	AC
Remote control type	Magic Remote
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)	SimpLink
Screen shape	Flat
Response time	- ms
Display diagonal	48 \
Display brightness	- cd/m²
Display technology	OLED evo
Native aspect ratio	16:9
Native refresh rate	100 Hz
Display diagonal (metric)	120.7 cm
Motion interpolation technology	OLED Motion
Stand type	Center stand
Product color	Black
Music apps	Amazon Music, Apple Music, BBC Sounds, Deezer, Spotify, TIDAL
Video apps	All 4, Amazon Prime Video, Apple TV, BBC iPlayer, BritBox, Chili, DAZN, Disney+, Freeview Play, ITV Hub, My5, NOW TV, Netflix, Rakuten TV, Twitch, YouTube
Smart modes	Cinema, Energy saving, Filmmaker, Standard, Vivid
Sports apps	DAZN, Sports Alerts
Operating system version	23
Operating system installed	Web OS

Weight and Dimensions

Stand width	470 mm
Depth (with stand)	230 mm
Height (with stand)	675 mm
Weight (with stand)	16800 g
Depth (without stand)	46.9 mm
Width (without stand)	1071 mm
Height (without stand)	618 mm
Weight (without stand)	14900 g
