LG PF510Q User Manual

12
ENGLISH
How to Install the Projector On a Tripod
• You can install the projector using a camera tripod.
• As shown below, you can mount the projector instead of a camera on the tripod.
• When stabilizing the tripod, we recommend using a locking bolt of standard
size 4.5mm (0.1inches) or less. The maximum size allowed for the locking bolt
is 5.5mm (0.2inches). (If it is longer than the maximum allowed size, it may
damage the projector.)
The projector is
connected to this part.
Tripod
Bolt used to attach the
projector to the tripod
Bottom of the
Projector
CAUTION
• If you are using a tripod, be careful not to apply external force to the tripod.
Doing so may damage the projector.
• Do not place the tripod on an unstable surface.
• Be sure to use a tripod with a maximum load capacity of 3kg (6.6lbs) or more.
• To use the projector safely, position the tripod legs so that they are as wide and
stable as possible and be sure to securely attach the projector to the tripod.

LG PF510Q Specifications

General

Resolution	1920 x 1080 (Full HD)
Brightness	450 ANSI Lumens
Contrast Ratio	100, 000:1
Light Source	LED
Throw Ratio	1.2:1
Display Technology	DLP
HDR	HDR10
Operating System	webOS
Power Consumption	65W
Lamp Life	Up to 30, 000 hours
Connectivity	Wi-Fi, Bluetooth
Keystone Correction	Vertical ±40 degrees
Inputs/Outputs	HDMI, USB
Audio Output	5W speaker
