13
ENGLISH
Using SIMPLINK
With a single remote control, you can easily manage various devices such as a soundbar
or set-top box connected to a projector with HDMI.
• Up to three devices can be connected and used simultaneously.
1 Connect the SIMPLINK HDMI Output port to the projector’s HDMI IN port with
an HDMI
®
cable.
2 Select (Q. Settings) [General] [Devices] [HDMI Settings].
3 Set [SIMPLINK (HDMI-CEC)] to [On].
4 Turn on the connected device. When the projector automatically connects to
the device, the input will switch. If the device is not automatically connected to
the projector, click the button.
• This feature works only with devices with the logo. Check for the
SIMPLINK logo on the external device. There may be a problem using the device
if the device does not meet the required specifications.
• A high-speed HDMI
®
cable with CEC (Consumer Electronics Control) function is
required to use SIMPLINK. Pin 13 of the high-speed HDMI
®
cable is used for data
transfer between devices.
• If you want to output sound to the external audio equipment connected through
the HDMI
®
cable, set [SIMPLINK (HDMI-CEC)] to [On].

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG PF510Q and is the answer not in the manual?

LG PF510Q Specifications

General IconGeneral
Resolution1920 x 1080 (Full HD)
Brightness450 ANSI Lumens
Contrast Ratio100, 000:1
Light SourceLED
Throw Ratio1.2:1
Display TechnologyDLP
HDRHDR10
Operating SystemwebOS
Power Consumption65W
Lamp LifeUp to 30, 000 hours
ConnectivityWi-Fi, Bluetooth
Keystone CorrectionVertical ±40 degrees
Inputs/OutputsHDMI, USB
Audio Output5W speaker
