LG PH1 User Manual

Getting Started 7
Getting Started
1
Main Unit
a hb i
c f jd g ke
a
MIC
b
BLUETOOTH LED
c
Receives or redials on the Bluetooth device.
(Refer to the page 10.)
d
T
Starts or pauses playback on the Bluetooth
mode.
e
Turns On / Off : Press and hold it.
f p
: Turn down the volume.
g
o
: Turn up the volume.
h
Battery LED
i
Turns on mood LED light. (Refer to the page 11.)
j
Portable In connector
Listens to music from your portable device.
k
USB port for charging

LG PH1 Specifications

General

Number of speakers	-
Audio output channels	- channels
AUX in	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Volume control	Digital
Recommended usage	Mobile phone / Smartphone
Battery type	Built-in
Battery voltage	3.7 V
Battery capacity	700 mAh
Power source type	Battery
Battery life (max)	5 h
Battery recharge time	3 h
Cables included	Mini-USB
RMS rated power	- W

Weight and Dimensions

Depth	82 mm
Width	81 mm
Height	88 mm
Weight	270 g
