Specifications
General
Power requirements
19 V
0
1.7 A (AC adapter)
Built-in rechargeable battery
Power consumption Refer to the main label.
AC adapter
y
Model :
LCAP25A
y
Manufacturer : Lien Chang Electronic Enterprise Co., Ltd.
y
Input : 100-240 V~ 50-60 Hz
y
Output :
19
V
0
1.7
A
Dimensions (W x H x D)
Approx. 320 mm X 167 mm X 152 mm
(12.60 inch x 6.57 inch x 6.00 inch)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 60 %
Water-proof IPX5
Inputs
PORT. IN 0.5 Vrms (3.5 mm stereo jack)
Battery
Battery capacity
7.4 Vdc, 5200 mAh (Typ)
7.4 Vdc, 5000 mAh (Min)
Operating time
Approx. 22 hours.
It may vary depending on the battery status and operational conditions.
Charging time
Less than 3.5 hours (with AC Adapter).
It can be varied depending on the conditions of the battery or operation.
y
Design and specications are subject to change without notice.
