4 AHU Control Kit / EEV Kit
Installation Scene
Installation Scene
Signal
Pipe
Thermistor
10
6
8
9
7
2
4
3
1
5
Air flow
Refrigerant flow
(Cooling)
Refrigerant flow
(Heating)
1
2
3
4
5
Air Handling Unit
Outdoor Unit
AHU Control Kit(PRCKA0)
AHU EEV Kit(PRLK048A0)
Field piping
Field supply
Multi_V
-
-
Field supply
Parts and components
6
7
8
9
10
Control kit wiring
Pipe thermistors (EBG36949304/EBG36949305)
Room thermistor (EBG36949303)
Remote controller(PQRCUSA0)
Dry contact PCB(PQDSBNGCM0)
(Power supply and communication between control kit and outdoor unit)
Evaporator (In/Out) control of Air Handling Unit
Return air control
Optional accessory
Optional accessory
Wiring connections
No. Name Remarks
