LG RAD136 - Specifi Cations

Appendix 21
Appendix
5
Specifi cations
General
Model RAT376B RAD226B RAD136/ RAD136B
Power requirements 200 - 240 V ~ 50 / 60 Hz
Power consumption 60 W 60 W 30 W
Dimensions (W x H x D) 202 x 307 x 297.5 mm without foot
Net Weight (Approx.) 3.4 kg 3.2 kg 3.1 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) DC 5 V
0
500 mA
Inputs/ Outputs
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Ampli er
Model RAT376B RAD226B RAD136/ RAD136B
Stereo mode
110 W + 110 W
(4 Ω at 1 KHz,
THD 10 %)
110 W + 110 W
(4 Ω at 1 KHz,
THD 10 %)
65 W + 65 W
(4 Ω at 1 KHz,
THD 10 %)
Surround
mode
Front
Subwoofer
110 W + 110 W
(4 Ω at 1 KHz,
THD 10 %)
150 W
(3 Ω at 60 Hz,
THD 10 %)
CD
Frequency Response 40 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
