LG RK1D User Manual

5 Appendix
Appendix
25
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D) Approx. 235 mm x 947 mm x 250 mm
Operating temperature 15 °C to 35 °C
Operating humidity 60 %
Inputs
Analog audio in (AUX IN) 0.6 Vrms (1 kHz, 0 dB), 600
Ω
, RCA jack (L, R) .
Portable in (PORT. IN) 0.4 Vrms (3.5 mm stereo jack) x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 40 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB) 5 V
0
500 mA
Amplier (RMS Output power)
Total output 60 W RMS
Front 15 W RMS X 2 (3
Ω
at 1 kHz, 10 % THD)
Sub Woofer 30 W RMS X 1 (4
Ω
at 1 kHz, 10 % THD)
y
Design and specications are subject to change without notice.

LG RK1D Specifications

General

Brand	LG
Model	RK1D
Category	Speaker System
Language	English
