1.1 Specifications
Multi Multiple type
1. S32W14ULGA0.EC6BEEU [RM2U15.U18]
Major Minor
Classification Chassis - U18A
Case 1 - 220-230-240, 1, 50
Case 2 - -
Limit Range of Voltage(Case 1) V 198 ~ 264
Limit Range of Voltage(Case 2) V -
Testing Combination - Model x No.
S3NW09JMQFA*1EA/S3NW12JMQFA*1EA
kW 4.10
Btu/h 14,000
kW 0.88~4.72
Btu/h 3,000~16,100
kW 4.69
Btu/h 16,000
kW 0.97~5.39
Btu/h 3,300~18,400
Rated kW
1.03
Min ~ Max kW 0.23~1.39
Rated kW 1.07
Min ~ Max kW 0.24~1.46
EER W/W
4.00
COP W/W 4.38
SEER Wh/Wh 8.09
SCOP Wh/Wh 4.00
Seasonal Energy Label (Cooling /
Heati
- A++ / A+
Pdesign(Cooling) kW 4.10
Pdesign(@-10℃, Heating) kW 3.60
Annual Energy Consumption Cooling / Heating kWh 177 / 1,259
Running Current Maximum Running Current A 11.0
Power Factor(Cooling/Heating) Rated - 0.98 / 0.98
Type - Propeller
Air Flow Rate
m³/min x
No.
35.0 x 1
Max. External Static Pressure Pa -
Type - BLDC
Drive - -
Output W x No. 43
.0 x 1
Type - Twin Rotary
Model x No. - DST102MA x 1
Motor Type - BLDC
Motor Output W x No. 900 x 1
Oil Type - FW68D
Oil Charging amount cc x No. 280 x 1
Rows x Columns x FPI - 2 × 24 ×14
No. - 1
Fin Type - Wide Louver Plus
Material (Tube/Fin) - CU / AL
Face Area m² 0.41
Net(W x H x D) mm 770 x 545 x 288
Shipping(W x H x D) mm 920 x 588 x 388
Net kg 32.5
Shipping kg 35.2
Power Input(Cooling)
Power Input(Heating)
Efficiency
Outdoor Fan
Outdoor Fan Motor
Compressor
Heat Exchanger
Dimensions
Weight
Power Supply
Rated
Cooling Capacity
Min ~ Max
Rated
Heating Capacity
Min ~ Max
Category
Unit
S32W14ULGA0.EC6BEEU [RM2U15.U18]
