5 Appendix
Appendix 45
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D)
Approx. Approx. 330.0 mm x 685.0 mm x 344.0 mm
(13.0 inch x 27.0 inch x 13.5 inch)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 60 % RH
Inputs
Digital audio in (OPTICAL IN) 3.3 V (p-p), Optical jack x 1
Microphone (MIC IN) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1
Guitar (GUITAR IN) Sensitivity 190 mV (1 kHz), 6.3 mm jack x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 250 to 20,000 Hz
Signal-to-noise ratio More than 80 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Available Digital Input Audio format Dolby Audio, PCM
y Design and specications are subject to change without notice.
