Mounting the main
unit on a wall
Mounting the main unit on a wall, you should
connect all the cables for operating the unit. For
details, refer to the page 13.
You can mount the main unit on a wall.
Prepare screws and brackets.
Main unit
Wall bracket
Shaft for wall
mount
Wall bracket install
guide
1. Detach the foot stand from the main unit.
2. Put the shafts on the bottom of the main unit
and fix it firmly by using the screws that have
been loosened on step 1.
3. Match the TV’s BOTTOM EDGE of Wall bracket
install guide with the bottom of TV and attach
to the position.
TV
