LG SH3B User Manual

Getting Started 3
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery from the
equipment: Remove the old battery or battery pack,
follow the steps in reverse order than the assembly.
To prevent contamination of the environment and
bring on possible threat to human and animal health,
the old battery or the battery put it in the appropriate
container at designated collection points. Do not
dispose of batteries or battery together with other
waste. It is recommended that you use local, free
reimbursement systems batteries and accumulators.
The battery should not be exposed to excessive heat
such as sunshine, re or the like.
Symbols
~
Refers to alternating current (AC).
0
Refers to direct current (DC).
Refers to class II equipment.
1
Refers to stand-by.
!
Refers to “ON” (power).
Refers to dangerous voltage.
POWER: This unit operates on a mains supply of
200 - 240 V ~, 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363
approved main plug. When replacing the fuse, always
use of the same rating approved to BS 1362. Never
use this plug with the fuse cover omitted. To obtain
a replacement fuse cover contact your dealer. If the
type of plug supplied is not suitable for the mains
sockets in your home, then the plug should be
removed and a suitable type tted. Please refer to
the wiring instructions below:
Warning: A mains plug removed from the mains lead
of this unit must be destroyed. A mains plug with
bared wires is hazardous if inserted in a mains socket.
Do not connect either wire to the earth pin, marked
with the letter E or with the earth symbol
6
or
coloured green or green and yellow. If any other plug
is tted, use same rating of fuse in the plug.
Important: The wires in this mains lead are coloured
in accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours
of the wires in the mains lead of this unit may not
correspond with the coloured marking identifying
the terminals in your plug, proceed as follows: The
wire which is coloured blue must be connected to
the terminal which is marked with the letter N or
coloured black. The wire which is coloured brown
must be connected to the terminal which is marked
with the letter L or coloured red.

LG SH3B Specifications

General

Audio decoders	DTS Digital Surround, Dolby Digital
RMS rated power	300 W
Audio output channels	2.1 channels
Impedance	4 Ω
Tweeter diameter	20 mm
Number of tweeter drivers	2
Soundbar speaker RMS power	100 W
Woofer diameter (imperial)	2.2 \
Signal-to-Noise Ratio (SNR)	82 dB
Bass reflex	Yes
Subwoofer type	Active subwoofer
Subwoofer location	Separate
Subwoofer sensitivity	85 dB
Docking connector type	-
Subwoofer driver diameter (imperial)	6 \
Wi-Fi	No
Audio (L/R) in	1
Bluetooth version	4.0
HDMI ports quantity	0
Connectivity technology	Wired & Wireless
Product color	Black
Audio formats supported	LPCM
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	27 W
Package depth	223 mm
Package width	1016 mm
Package height	430 mm
Package weight	9800 g

Weight and Dimensions

Depth	47 mm
Width	950 mm
Height	71 mm
Soundbar weight	2470 g
Subwoofer depth	261 mm
Subwoofer width	171 mm
Subwoofer height	390 mm
Subwoofer weight	5600 g
Main unit dimensions (WxDxH)	950 x 47 x 71 mm
