LG SJ7 Service Manual

1-1
Copyright © 2017 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
CONTENTS
SECTION 1 ........ GENERAL
SECTION 2 ........ CABINET & MAIN CHASSIS
SECTION 3 ........ ELECTRICAL
SECTION 4 ........ WIRELESS SUBWOOFER PART

LG SJ7 Specifications

General

Audio decoders	DTS Digital Surround, Dolby Digital
RMS rated power	320 W
Audio output channels	4.1 channels
Audio Return Channel (ARC)	Yes
Product color	Black
TV stand usage	No
Recommended usage	Universal
Audio formats supported	LPCM
HDMI in	1
HDMI version	1.4
Bluetooth version	4.0
Connectivity technology	Wired & Wireless
Digital audio coaxial in	0
Apple docking compatibility	Not supported
Cables included	Optical
Receiver included	-
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Subwoofer type	Active subwoofer
Subwoofer connectivity	Wireless

Weight and Dimensions

Depth	109 mm
Width	340 mm
Height	74 mm
Subwoofer depth	252 mm
Subwoofer width	171 mm
Subwoofer height	320 mm
Subwoofer weight	4200 g
