LG SN5R User Manual

Connecting 23
Connecting
2
LG Sound Sync with wired connection
1. Connect your LG TV to the unit by using an
optical cable.
Optical
cable
2. Set up the sound output of TV to listen to the
sound through this unit :
(Refer to the TV’s instruction manual for the
details of LG Sound Sync.)
3. Turn on the unit by pressing
1
.
4. Select the input source to OPT/HDMI ARC by
pressing F repeatedly.
You can see “LGOPT” on the display window if
connecting normally between this unit and your
TV.
LG Sound Sync with wireless
connection
1. Turn on the unit by pressing
1
.
2. Select the LG TV function by pressing F
repeatedly.
3. Set up the sound output of TV to listen to the
sound through this unit :
“PAIRED” appears on the display window for
about 3 seconds and then you can see “LG TV”
on the display window if connecting normally
between this unit and your TV.
(Refer to the TV’s instruction manual for the
details of LG Sound Sync.
If you turned off the unit directly by pressing
1
(Power), LG Sound Sync (Wireless) will be
disconnected.
,
Note

LG SN5R Specifications

General

Audio decoders	DTS Digital Surround, DTS Virtual:X, Dolby Digital
RMS rated power	520 W
Audio output channels	4.1 channels
Audio Return Channel (ARC)	Yes
Wi-Fi	No
HDMI version	1.4
Bluetooth version	4.0
HDMI ports quantity	-
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Subwoofer connectivity	Wireless
Soundbar speaker RMS power	300 W
Product color	Black
Country of origin	China
Audio formats supported	AAC, AAC+, LPCM
Consumer Electronics Control (CEC)	SimpLink
Number of products included	1 pc(s)
Package depth	426 mm
Package width	946 mm
Package height	233 mm
Package weight	12900 g

Weight and Dimensions

Depth	85 mm
Width	890 mm
Height	57 mm
Soundbar weight	2350 g
Subwoofer depth	290 mm
Subwoofer width	180 mm
Subwoofer height	394 mm
Subwoofer weight	5800 g
