LG SPH4B-W Service Manual

Copyright © 2021 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
2-102-9
• Main unit parts list
S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS
ASSEMBLY PARTS
A41 ABQ77200109 Case Assembly SL4Y CASE TOP ASSY_EVA DELETE_
A42 ABQ77160313 Case Assembly SL4 VI CASE BOTTOM ASSY
A46 EBT65893033 LFS Total PCB Assembly 00 51 05 A2 42 42 00 53 4E 43
A52 EAT62833604 Module,Bluetooth MB8811C1TN CSR8811 Argentina H
A54 EAT63117405 Module,RF Full Module(RxTx) WL1NB6V2_ETWADYEC01 0DBM 0DB 0
A55 EBR88178301 PCB Assembly SL4/SL5 Key TOTAL ASSY
A80L ABQ76481708 Case Assembly SL4 Case Assy L Chamber
A80R ABQ76481709 Case Assembly SL4 Case Assy R Chamber
INDIVIDUAL PARTS
253 ABH76819601 Button Assembly SL5 Button Assy
262 MCQ62096488 Damper CUTTING THERMOPLASTIC HOME THE
264 AEJ74999618 Holder Assembly HOME THEATER SL5YF ABS AF365 H
265 AEJ75439405 Holder Assembly HOME THEATER SL5/SL4 Holder_Wi
266 EAJ63172305 LCD Module SMMD3276-A-00-VTNF-WX BACK LIG
CABLES
CABLE1 EAD65485502 Harness,Single CAV-18-39 SMH200-02 to SMH200-
CABLE2 EAD64105005 Cable,FFC AT10010105D01 105MM 1.00MM 10P
CABLE3 EAD62131522 Cable,FFC 26P005D-H2-1F01A-T-143-64-79-0
CABLE4 EAD62131525 Cable,FFC 26P005D-H2-2F01A-T-70-15-55-0-
