3-28
Copyright © 2021 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
4. USB
FIG 4-1. USB 5 V
FIG 4-2. USB D+
7
8
FIG 4-3. USB D-
9
9
8
7
USB_GND
USB5V
USB_N
USB_P
JK501
1
5V
2
D-
3
D+
4
DGND
C544
100nF
DGND
USB_5V
D502
D503
3
1
2
C546
10uF
C545
220uF
USB
56
