Copyright © 2021 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
2-122-11
• Main unit parts list
RUN DATE : 1-February-2021
S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS
ASSEMBLY PARTS
A41 AAX76827606 Board Assembly HOME SP8YA TOP case+Touch PCB
A42 ABQ76920212 Case Assembly SP8 NEW BK Spray Case Bottom A
A43 EBR32700401 PCB Assembly SP8 FRONT SVC ASSY -
A46 EBR32700301 PCB Assembly SP8 MAIN SVC ASSY -
A47 EBT66636201 LFS Total PCB Assembly SP8YA AMP LFS total -
A51 EAT64454802 Module,Wifi Bluetooth Module TWCM-K505D MT7668_Brazil 3.135
OR
A51 EAT64454801 Module,Wifi Bluetooth Module TWCM-K505D MT7668 3.135VTO3.6V
A54 EAT63117405 Module,RF Full Module(RxTx) WL1NB6V2_ETWADYEC01 0DBM 0DB 0
A80C ABQ77060902 Case Assembly SL8 Chamber Center
A80L ABQ77100408 Case Assembly SP8YA Front L New 2.5in WF
A80R ABQ77100508 Case Assembly SP8YA Front R New 2.5in WF
INDIVIDUAL PARTS
262 MCQ70767102 Damper CUTTING THERMOPLASTIC HOME THE
OR
262 MCQ62096433 Damper CUTTING THERMOPLASTIC DVD NB45
263 MCQ70767103 Damper CUTTING THERMOPLASTIC HOME THE
OR
263 MCQ62096483 Damper CUTTING THERMOPLASTIC HOME THE
266 AEJ75879401 Holder Assembly SPK SL8YG.DUSALLK HOLDER WI-FI
268 MBS64585501 Chassis PRESS SECC 1.0t SL8A PRESS Cha
LCD801 EAJ63172305 LCD Module SMMD3276-A-00-VTNF-WX BACK LIG
CABLES
CABLE1 EAD62131542 Cable,FFC 26P050D-H01-0F01A-T 70 70MM 0.
CABLE2 EAD63970514 Cable,FFC AT05026090C04 90MM 0.50MM 26P
CABLE3 EAD63970513 Cable,FFC AT05026370C01 370MM 0.50MM 26P
CABLE5 EAD65366201 Harness,Single CAV-18-29 12507HS-H12G1 to 125
To Next Page
