LG SPS7-W User Manual

57
Appendix
Specifications
General
Power requirements Refer to the main label.
Power Consumption Refer to the main label.
Dimensions (W x H x D) Approx. 890.0 mm x 61.5 mm x 126.0 mm (including the base)
Operation Temperature Range 5 °C - 35 °C
Operation Humidity Range 5 % - 80 % RH
Bus Power Supply (USB)
5 V 0 500 mA
Available Digital Input Audio Sampling
Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Available Digital Input Audio format
Dolby Digital, Dobly Digital Plus, Dolby TrueHD, Dolby Atmos,
DTS Digital Surround, DTS-HD HRA, DTS-HD MA, DTS:X, PCM
Input/Output
OPTICAL IN 3.0 V (p-p), (optical audio connection terminal) × 1
HDMI™ IN 19-pin (Type A, HDMI™ connection terminal) × 1
HDMI™ d TV (eARC / ARC)
19-pin (Type A, HDMI™ connection terminal) × 1
4K resolution is supported for 4K sources applied with HDCP 2.3
(supported 4K@120 Hz (YCbCr 4:2:0)).
Amplifier (RMS output)
Total 400 W RMS
Front 30 W RMS × 2 (Impedance: 6 Ω, THD 10 %)
Centre 30 W RMS (Impedance: 6 Ω, THD 10 %)
Top (Overhead) 30 W RMS × 2 (Impedance: 6 Ω, THD 10 %)
Top centre (Overhead) 30 W RMS (Impedance: 6 Ω, THD 10 %)
Subwoofer 220 W RMS (Impedance: 3 Ω, THD 10 %)
Appendix

LG SPS7-W Specifications

General

Brand	LG
Model	SPS7-W
Category	Speaker System
Language	English
