1
Technical Data
Model name
ST-1630F
Material
Aluminum Profile,Steel
Surface Finish
Power Coating (Matte Black)
Recommended Screen Size
163’’
Allowable Loads
300kg (Maximum)
Lift Range
0/200/400mm
Certification
CB,CE-LVD,ETL,RoHS2.0
Stand Dimension (W x D x H)
3097 x 1420 x 2200mm
3097 x 1420 x 2400mm
3097 x 1420 x 2600mm
Stand Base Dimension (W x D x H)
2007 x 1420 x 63mm
Caster Wheel Size (Diameter)
63mm
Wooden Case Dimension (W x D x H)
2088 x 1536 x 620 mm
Weight (Net/Gross)
150kg/230kg
This model (ST-1630F) is a stand for the LAEC018-GN2 AIO model only.
The stand has 3 levels to change the height of the screen and comes assembled as LEVEL 1.
The height can be changed if needed, and it is described on the page of 4.
The distance from the floor to the bottom of the screen is shown in the table.
Determine the height of your SCREEN and proceed first if you need to change the height of
the STAND.
Level
Height
Level 1
≈32cm
Level 2
≈52cm
Level 3
≈72cm
< Height: Level 1 >
< Height: Level 2 >
< Height: Level 3 >
