DATE: 2003. 5. 9.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
FB308 6210TCE003J BAS2550T BO SUNG 2550MM AXIA
FB309 6210TCE003J BAS2550T BO SUNG 2550MM AXIA
FB310 6210TCE003A BRD3510B BO SUNG 3510MM RADI
FB313 6210TCE003J BAS2550T BO SUNG 2550MM AXIA
FB402 971-0054 TIN 50MM TAPING
FB403 971-0054 TIN 50MM TAPING
FB701 6210TCE003L BAS3580T BO SUNG 3580MM AXIA
FB703 6210TCE003B BRS3580B BO SUNG 3580MM RADI
FB705 971-0054 TIN 50MM TAPING
FB903 6210TCE003P BRS2550B BO SUNG 2550MM RADI
FB904 971-0054 TIN 50MM TAPING
FB905 6210TCE003P BRS2550B BO SUNG 2550MM RADI
FB906 6210TCE003P BRS2550B BO SUNG 2550MM RADI
FB921 6210TCE003A BRD3510B BO SUNG 3510MM RADI
FB922 6210TCE003L BAS3580T BO SUNG 3580MM AXIA
FB952 6210TCE003G BRS3550B BO SUNG 3550MM RADI
L311 0LA0680K119 0.68UH K 2.3*3.4 TP
L312 0LA0680K119 0.68UH K 2.3*3.4 TP
L313 0LA0680K119 0.68UH K 2.3*3.4 TP
L702 6140TBZ025D - - H-SIZE,DR12*20-C6.0,150U
L703 6140TYZ010G LX31 GET DR14*15-C5.2,16.5T,
L705 6140TBZ026C DR15*18-C9.8 100UH 0.1*30MM
L901 6200TZZ004A SQE2626 NAMYANG BK L/FILTER
L903 6210TCE003G BRS3550B BO SUNG 3550MM RADI
Q501 0TR320209AA KTC3202-Y(KTC1959) TP KEC TO
Q502 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q503 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q705 0TR200009AB KTC200-Y TP KEC TO92 NPN
Q706 0TRFC10008A FJAF5804(TU) FAIRCHILD ST TO
Q707 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q708 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q709 0TR141300AB KTD1413 BK KEC TO220I S NPN
Q710 0TRKE90020A MPSA44 KEC TP TO92 500V 300M
Q711 0TF630000AC IRF630M BK SGS-THOMSON 200V
Q712 0TF630000AC IRF630M BK SGS-THOMSON 200V
Q713 0TF630000AC IRF630M BK SGS-THOMSON 200V
Q714 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q715 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q716 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q719 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5
Q720 0TR390409CA FAIRCHILD 2N3904(TA) TP TO-9
Q799 0TRKE90019A MPSA92 KEC TP TO92 -300V -50
Q901 0TF760000AD SSS7N60B FAIRCHILD ST TO220F
Q903 0TR100809AA KSC1008C-Y TP SAMSUNG TO92
Q941 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q942 0TR127309AA KTA1273-Y(KTA966A) TP KEC TO
Q951 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q952 0TR127309AA KTA1273-Y(KTA966A) TP KEC TO
Q953 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
R201 0RD1001Q609 1K 1/4W(3 5% TA52
R202 0RD0912Q609 91 OHM 1/4 W (3.4) 5% TA52
R203 0RD2200Q609 220 1/4W(3 5% TA52
R204 0RD4300Q609 430 OHM 1/4 W(3.4) 5.00% TA5
R205 0RD1001Q609 1K 1/4W(3 5% TA52
R206 0RD0912Q609 91 OHM 1/4 W (3.4) 5% TA52
DATE: 2003. 5. 9.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R207 0RD4300Q609 430 OHM 1/4 W(3.4) 5.00% TA5
R208 0RD2200Q609 220 1/4W(3 5% TA52
R209 0RD9100Q609 910 1/4W(3 5% TA52
R210 0RD2200Q609 220 1/4W(3 5% TA52
R211 0RD2200Q609 220 1/4W(3 5% TA52
R301 0RD0752Q609 75 1/4W(3 5% TA52
R302 0RD0752Q609 75 1/4W(3 5% TA52
R303 0RD0752Q609 75 1/4W(3 5% TA52
R305 0RN6201F409 6.20K 1/6W 1% TA52
R314 0RD1000Q609 100 1/4W(3 5% TA52
R315 0RD1000Q609 100 1/4W(3 5% TA52
R319 0RD4701Q609 4.70K 1/4W(3 5% TA52
R320 0RD4701Q609 4.70K 1/4W(3 5% TA52
R326 0RD2201Q609 2.20K 1/4W(3 5% TA52
R327 0RD1001Q609 1K 1/4W(3 5% TA52
R328 0RD1001Q609 1K 1/4W(3 5% TA52
R329 0RD1001Q609 1K 1/4W(3 5% TA52
R330 0RD1001Q609 1K 1/4W(3 5% TA52
R331 0RD1600Q609 160 1/4W(3 5% TA52
R332 0RD1600Q609 160 1/4W(3 5% TA52
R333 0RD1600Q609 160 1/4W(3 5% TA52
R334 0RD3303Q609 330K 1/4W(3 5% TA52
R335 0RD3303Q609 330K 1/4W(3 5% TA52
R336 0RD3303Q609 330K 1/4W(3 5% TA52
R337 0RD1000Q609 100 1/4W(3 5% TA52
R338 0RD0471Q609 4.70 1/4W(3 5% TA52
R340 0RN1002F409 10K 1/6W 1 TA52
R341 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R342 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R343 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R344 0RD0332Q609 33 1/4W(3 5% TA52
R345 0RD0332Q609 33 1/4W(3 5% TA52
R346 0RD0332Q609 33 1/4W(3 5% TA52
R347 0RD1200Q609 120 1/4W(3 5% TA52
R401 0RD1000Q609 100 1/4W(3 5% TA52
R402 0RD5600Q609 560 1/4W(3 5% TA52
R403 0RD1002Q609 10K 1/4W(3 5% TA52
R405 0RD2001Q609 2K 1/4W(3 5% TA52
R406 0RD2001Q609 2K 1/4W(3 5% TA52
R407 0RD1300Q609 130 1/4W(3 5% TA52
R408 0RD1300Q609 130 1/4W(3 5% TA52
R409 0RD1000Q609 100 1/4W(3 5% TA52
R411 0RD3901Q609 3.90K 1/4W(3 5% TA52
R412 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R415 0RD1301Q609 1.30K 1/4W(3 5% TA52
R416 0RD4701Q609 4.70K 1/4W(3 5% TA52
R417 0RD1000Q609 100 1/4W(3 5% TA52
R418 0RD1002Q609 10K 1/4W(3 5% TA52
R419 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R420 0RD2001Q609 2K 1/4W(3 5% TA52
R424 0RD2200Q609 220 1/4W(3 5% TA52
R425 0RD4701Q609 4.70K 1/4W(3 5% TA52
R426 0RD4701Q609 4.70K 1/4W(3 5% TA52
R429 0RD1000Q609 100 1/4W(3 5% TA52
R430 0RD1000Q609 100 1/4W(3 5% TA52
R431 0RD1000Q609 100 1/4W(3 5% TA52
R432 0RD1000Q609 100 1/4W(3 5% TA52
R433 0RD1000Q609 100 1/4W(3 5% TA52
R434 0RD1000Q609 100 1/4W(3 5% TA52
R438 0RD1001Q609 1K 1/4W(3 5% TA52
R439 0CN1010K519 100P 50V K B TA52
R446 0RD1002Q609 10K 1/4W(3 5% TA52
- 27 -
TRANSISTOR
RESISTORs
