LG Styler S3RERB - Page 42

42
6-1-3. Operation of Circulation Circuits
No.
Part name Details of operation
Refrigerant gas status (inlet/
outlet)
1
Compressor It compresses the refrigerant from low
pressure (5 kgf/
㎠
) to high pressure (15
~ 18 kgf/
㎠
).
Low pressure gas
→
High pressure
gas
Temperature (30
℃
)
→
(80 - 120
℃
)
2
Condenser
and Hot Line
Pipe
As the high pressure refrigerant
releases its heat to outside, it turns into
liquid.
High pressure gas
→
High pressure
liquid
Temperature (80 - 120
℃
)
→
(40 - 60
℃
)
3
Dryer It contains moisture absorbent that
absorbs the moisture in circulation
circuit. (Moisture absorbent)
4
Evaporator Low pressure 2-phase refrigerant
absorbs heat and turns into low
pressure gas.
Low pressure liquid
→
Low pressure
gas
Temperature (0 - 20
℃
)
5
Suction pipe It connects the evaporator and
compressor.
Low pressure gasLow pressure gas
Temperature (10 - 30
℃
)
→
(30
℃
)
* When the low pressure liquid refrigerant turns into gas on the evaporator, the evaporation occurs
throughout the entire case from inlet to outlet, causing the noise of owing liquid. Noise may or may
not occur depending on the load condition inside the case. This is not a product failure.
6-2. Refrigerant
6-2-1. Overview of Refrigerant
Name of
refrigerant
Properties ODP* GWP** Remarks
R134a
The refrigerant does not contain chlorine, which is
recognized as the cause of ozone layer destruction,
and GWP level is signicantly lower than that of the
previous R12 (GWP: 15300).
0 1200 Refrigerant
* ODP: Ozone Depletion Potential (relative value calculated when CFC11 corresponds to 1.0)
** GWP: Global Warming Potential (relative value calculated when CO2 corresponds to 1.0)
